FINDER 202380244000 Industrial Control Relay
This is a 24 VAC alternating/sequence relay with a coil voltage of 24 volts. It features a contact configuration of one normally open and one normally closed contact, handling up to 16 amps. Suitable for DIN rail mounting, it includes cadmium-free contacts and offers options for different switching sequences. The relay provides reliable switching for various automation applications, with a rated voltage of 250V AC and a maximum peak current of 30A. It includes safety features like insulation between coil and contacts, and is designed for high durability and efficiency in industrial control systems.
FINDER 202380244000 Industrial Control Relay Specifications:
- Coil Voltage: 24 V AC
- Contact Configuration: 1 NO + 1 NC (SPST-NO + SPST-NC)
- Rated Current: 16 A
- Maximum Peak Current: 30 A
- Rated Voltage: 250 V AC
- Maximum Switching Voltage: 400 V AC
- Rated Load AC1: 4000 VA
- Rated Load AC15: 750 VA
- Contact Material: Cadmium free
- Mechanical Life: 300,000 cycles at rated load
- Electrical Life: 100,000 cycles at rated load
- Insulation Between Coil and Contacts: 4 kV
- Ambient Temperature Range: -40°C to +40°C
- Protection Category: IP 20
- Mounting: 35 mm DIN rail (EN 60715)
Buy the Buy Finder Relay Part Number 202380244000 Online
Purchase the Finder industrial control relay 202380244000 online to ensure seamless automation in your control systems. Designed for DIN rail mounting, it offers high durability with cadmium-free contacts, rated at 16 amps for reliable operation. Its versatile features include multiple switching sequences and high insulation standards, making it ideal for demanding industrial environments. Benefit from fast delivery and competitive pricing by ordering online today—enhance your automation setup with this dependable relay for lasting performance and safety.
Buy Finder relay 202380244000 now and experience reliable switching and industrial automation efficiency with this high-quality DIN rail relay.
Frequently Asked Questions
Where can I buy FINDER 202380244000?
You can click on the BUY or RFQ button to purchase 202380244000 from an authorized FINDER distributor.
How do I troubleshoot issues or seek technical support for part 202380244000?
You can download the 202380244000 datasheet or visit the FINDER website for support.
Who is the manufacturer of 202380244000?
FINDER
