FINDER 361190054011 Miniature PCB Relay
The FINDER 36.11.9.005.4011 is a miniature PCB relay designed for space-constrained applications requiring reliable switching. It boasts a 10A current carrying capacity and a single-pole double-throw (SPDT) contact configuration. The relay's compact “sugar cube” package minimizes its footprint, while the RT III wash tight protection ensures durability in harsh environments. Constructed with AgSnO2 contact material, it provides excellent conductivity and longevity. This relay is suitable for a wide range of industrial automation, control panels, and general-purpose switching applications.
FINDER 361190054011 Miniature PCB Relay Specifications:
- Contact Material: AgSnO2
- Contact Configuration: 1 CO (SPDT)
- Rated Current: 10 A
- Maximum Peak Current: 15 A
- Rated Voltage: 250 V AC
- Maximum Switching Voltage: 250 V AC
- Rated Load AC1: 2,500 VA
- Rated Load AC15 (230 V AC): 500 VA
- Single Phase Motor Rating: 0.37 kW
- Breaking Capacity DC1: 10/0.3/0.12 A (30/110/220 V)
- Minimum Switching Load: 300 mW (6/1,000 V/mA)
- Coil Type: DC
- Nominal Voltage (UN): 3 - 48 V DC
- Rated Coil Consumption: 7.5 - 120 mA
- Ambient Temperature Range: -40…+85 °C
- Environmental Protection: RT III
- Mechanical Life: 10 · 10^6 cycles
- Electrical Life at Rated Load AC1: 50 · 10^3 cycles
- Operate/Release Time: 10/5 ms
- Insulation Between Coil and Contacts: 3 kV
- Dielectric Strength Between Open Contacts: 750 V AC
- Shock Resistance: 10 g
