FINDER 9612SMA Miniature Power Relay
The Finder 96.12.SMA is a versatile miniature power relay suitable for a wide range of industrial applications. Its compact design and plug-in configuration allow for easy integration and maintenance. The relay offers both AC and DC coil options, providing flexibility in power supply choices. Features include a flange mount option for secure installation, a lockable test button for reliable testing, and a mechanical flag indicator for visual status confirmation. Cadmium-free contacts contribute to environmentally responsible operation. This relay is ideal for control circuits, lighting systems, and various automation equipment.
FINDER 9612SMA Miniature Power Relay Specifications:
- Rated Current: 12 A
- Maximum Peak Current: 20 A
- Rated Voltage: 250 V AC
- Maximum Switching Voltage: 400 V AC
- Rated Load AC1: 3,000 VA
- Rated Load AC15 (230 V AC): 500 VA
- Single Phase Motor Rating: 0.55 kW
- Breaking Capacity DC1: 12 A
- Minimum Switching Load: 500 mW
- Contact Material: AgNi
- Coil Voltage: 6-12-24-48-60-110-120-230-240 V AC / 6-12-24-48-60-110-125-220 V DC
- Mechanical Life: 20 · 10^6 cycles
- Electrical Life: 200 · 10^3 cycles
- Operate/Release Time: 8/8 ms
- Insulation Between Coil and Contacts: 4 kV
- Dielectric Strength: 1,000 V AC
- Ambient Temperature Range: –40…+70 °C
Buy the 96.12.SMA Finder Miniature Power Relay | myMectronic
Purchase the Finder 96.12.SMA power relay securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy FINDER 9612SMA?
You can click on the BUY or RFQ button to purchase 9612SMA from an authorized FINDER distributor.
How do I troubleshoot issues or seek technical support for part 9612SMA?
You can download the 9612SMA datasheet or visit the FINDER website for support.
Who is the manufacturer of 9612SMA?
FINDER
