Glenair 809015 Crimp Contacts
This product includes #23 crimp contacts designed for use with Mighty Mouse series USB and micro connectors, offering reliable crimping for #22 to #28 AWG wires. Crafted from beryllium copper with gold plating, these contacts support high current ratings of up to 5 Amps and operate within a temperature range of -65°C to +200°C. The set includes a precision crimping tool and positioner, ensuring gas-tight, high-strength terminations suitable for various electronic and USB applications.
Glenair 809015 Crimp Contacts Specifications:
- Current Rating: 5 Amps maximum
- Voltage Drop: 70 millivolts maximum at 5 Amps and 25°C
- Temperature Range: -65°C to +200°C
- Material: Beryllium copper alloy with 50 microinches gold plating over nickel underplate
- Wire Size: #22 - #28 AWG, with options for smaller bore for #26-#30 AWG
- Contact Type: Pin and socket types with inspection holes
- Crimping Tool: M22520/2-01 with adjustable settings and ratchet mechanism
- Application: USB, micro, thermocouple, and high-reliability electronic connections
- Dimensions: Tool length 6.75 inches, weight approximately 10 oz
- Certification: Meets ASTM B196/B197 standards for beryllium copper, passivated stainless steel contact hood
Buy the Buy Lenair USB and RJ45 Contact Part Number 809015 Online
Order the Lenair #23 crimp contacts for USB and Micro connectors online today and ensure reliable, gas-tight terminations for your electronic projects. These high-quality contacts are designed for optimal performance with wire sizes #22 to #28 AWG and include precision tools such as the M22520/2-01 crimper and positioner. Suitable for USB, micro, and thermocouple applications, these contacts support high current ratings up to 5 Amps and operate over a wide temperature range. Secure high-quality crimps with ease and confidence by purchasing directly from us today.
Buy Lenair 809015 now and experience unmatched reliability and high-performance crimping for USB and micro connectors.
Frequently Asked Questions
Where can I buy Glenair 809015?
You can click on the BUY or RFQ button to purchase 809015 from an authorized Glenair distributor.
How do I troubleshoot issues or seek technical support for part 809015?
You can download the 809015 datasheet or visit the Glenair website for support.
Who is the manufacturer of 809015?
Glenair
