Grayhill 25LB10Q Rotary Encoder
The 25LB10-Q is an affordable single-deck rotary encoder that features a durable black thermoplastic housing and quadrature output. It is designed for precision and longevity, supporting up to 250mA current at 28VDC. It includes high-quality components such as gold-plated contacts, stainless steel detent balls, and a tin-plated mounting bracket, ensuring reliable operation. With a 10° angle of throw over 36 positions, it withstands extensive use with a lifecycle of 100,000 cycles. Operational from -40°C to 85°C, it is suitable for sensing, instrumentation, and control applications.
Grayhill 25LB10Q Rotary Encoder Specifications:
- Housing Material: Reinforced thermoplastic
- Detent Ball: Stainless steel, nickel-plated
- Detent Spring: Tinned music wire
- Contacts: Beryllium copper, gold plate over nickel
- Terminals: Copper alloy, solder plate over nickel
- Output: Quadrature 2-bit code
- Angle of Throw: 10°
- Positions: 36
- Current Rating: 250mA at 28VDC
- Contact Resistance: 75 milliohms
- Insulation Resistance: 1000 megaohms minimum
- Voltage Breakdown: 1000VAC minimum
- Life Cycle: 100,000 cycles
- Operating Temperature: -40°C to +85°C
- Mounting Hardware: Tin-plated stainless steel bracket
- Housing Color: Black
- Rotation: Continuous
Buy the Grayhill Series 25L Rotary Encoder: 25LB10Q
Order the Grayhill Series 25L Rotary Encoder 25LB10Q online today to benefit from its durable design, precise quadrature output, and long-lasting performance. With a robust thermoplastic housing, gold-plated contacts, and a lifecycle of 100,000 cycles, this compact and reliable encoder is ideal for sensing, instrumentation, and control applications. It supports a 10° angle of throw across 36 positions, operates efficiently from -40°C to 85°C, and includes high-quality stainless steel detent balls and copper alloy terminals for dependable operation in demanding environments. Purchase now to ensure seamless integration into your systems.
Buy Grayhill 25LB10Q now and experience unmatched reliability and performance in sensing and instrumentation applications.
Frequently Asked Questions
Where can I buy Grayhill 25LB10Q?
You can click on the BUY or RFQ button to purchase 25LB10Q from an authorized Grayhill distributor.
How do I troubleshoot issues or seek technical support for part 25LB10Q?
You can download the 25LB10Q datasheet or visit the Grayhill website for support.
Who is the manufacturer of 25LB10Q?
Grayhill
