Grayhill 76SB06T Panel Switch
The Series 76 SPST Rocker switches are designed with raised, recessed, and Piano-DIP® styles, featuring sealed bases, spring and ball contacts, and optional top tape seals. They offer versatile operation options such as UP being open or closed, with multiple position and length configurations for different applications. Approved for industrial use, these switches provide high durability, excellent electrical properties, and environmental resistance, making them suitable for control panels, machinery, and automation systems requiring reliable switching solutions with RoHS compliance.
Grayhill 76SB06T Panel Switch Specifications:
- Mechanical Life: 10,000 operations per switch position
- Make-and-break Current Rating: 150 mA, 30 Vde; 50 mA, 125 V ac
- Contact Resistance: Initial <30mQ, After life <30mQ
- Insulation Resistance: >5,000 MOhms at 100 Vde
- Dielectric Strength: 750 V AC initial, 750 V AC after life
- Current Carry Rating: 4 Amps maximum
- Switch Capacitance: 2 picofarads
- Operating Temperature Range: -40°C to +85°C
- Storage Temperature Range: -55°C to +85°C
- Vibration Resistance: Meets Method 204, Test Condition B
- Mechanical Shock: Meets Method 213, Test Condition A
- Moisture Resistance: MIL-STD-202, Method 106
- Solderability: Per MIL-STD-202, Method 208
- Resistance to Soldering Heat: Passes EIA Standard RS-448-2
- Materials: Brass, gold-plated; Copper alloy, gold-plated; Thermoplastic UL94V-O
- Potting Material: Epoxy (76,78 series), Polyimide film (90 series)
Buy the Buy Grayhill SPST Rocker Part Number 76SB06T Online
Order Grayhill 76SB06T rocker switch online today and ensure reliable performance for your automation projects. Designed for durability, sealed bases, and high electrical ratings, this switch is suitable for control panels and machinery. With multiple lengths and styles, it offers flexible installation options. Take advantage of fast shipping and expert support when you purchase from authorized distributors. Enhance your control solutions with the high-quality Grayhill Series 76 rocker switches, engineered to meet industrial standards and environmental requirements, providing long-term reliability.
Get Grayhill 76SB06T today—built for precision and long-lasting durability in industrial control systems.
Frequently Asked Questions
Where can I buy Grayhill 76SB06T?
You can click on the BUY or RFQ button to purchase 76SB06T from an authorized Grayhill distributor.
How do I troubleshoot issues or seek technical support for part 76SB06T?
You can download the 76SB06T datasheet or visit the Grayhill website for support.
Who is the manufacturer of 76SB06T?
Grayhill
