Grayhill 97C10ST Surface Mount Switch
The Series 97D DIP switch offers reliable short-pitch tactile switching, ideal for space-constrained electronic devices such as notebooks, radios, and industrial controls. Made with UL94V-0 nylon and gold-plated contacts, it features a durable mechanical life of 1,000 cycles, operating efficiently between -40°C and 85°C. Available in various positions from 2 to 10, it provides a contact rating of 25 mA at 24 Vdc. Its sealed design allows for alcohol-based cleaning, making it perfect for modern manufacturing processes where space optimization and durability are critical.
Grayhill 97C10ST Surface Mount Switch Specifications:
- Contact Rating: 25 mA at 24 Vdc, 100 mA at 50 Vdc
- Contact Resistance: 100 mΩ max, initially
- Insulation Resistance: 100 MΩ minimum at 100 Vdc
- Dielectric Strength: 300 Vac for one minute
- Switch Capacitance: 5 pF maximum
- Contact Arrangement: SPST
- Life: 1,000 cycles minimum
- Operation Force: 500 gF
- Operating Temperature Range: -40°C to 85°C
- Storage Temperature Range: -40°C to 85°C
- Materials: UL94V-0 Nylon base and cover, alloy copper with gold-plated contacts, brass terminals, Kapton tape seal
- Soldering: Supports vapor phase and IR-reflow at 255°C peak, robust against washing with alcohol-based solvents
Buy the Buy Grayhill Series97C10ST Part Number 97C10ST Online
Purchase the Grayhill Series97C10ST switch online today for your electronic projects. This reliable surface mount switch features 10 positions, RoHS compliance, and durable construction suitable for space-sensitive applications like notebooks and industrial controls. It supports vapor phase and IR-reflow soldering, withstands washing with alcohol-based solvents, and offers a life cycle of at least 1,000 cycles. Enhance your manufacturing process with this high-quality component designed for excellent longevity, space efficiency, and reliable switching performance.
Order your Grayhill Series97C10ST space-efficient switch today and ensure dependable operation in your compact electronic designs.
Frequently Asked Questions
Where can I buy Grayhill 97C10ST?
You can click on the BUY or RFQ button to purchase 97C10ST from an authorized Grayhill distributor.
How do I troubleshoot issues or seek technical support for part 97C10ST?
You can download the 97C10ST datasheet or visit the Grayhill website for support.
Who is the manufacturer of 97C10ST?
Grayhill
