Harting 09185065803 6P PCB Connector
The HARTING SEK-18 SV FE TYPA 06P PLS4 is a robust and reliable connector designed for PCB to cable applications. It offers 6 positions and is suitable for IDC flat cables with a 1.27 mm pitch. The connector's noble metal contacts ensure excellent conductivity and durability, while its V-0 flammability rating enhances safety. It is commonly used in industrial automation, control systems, and other applications requiring secure and high-performance connections.
Harting 09185065803 6P PCB Connector Specifications:
- Specification: SEK-18 SV FE TYPA 06P PLS4
- HARTING eCatalogue: https://b2b.harting.com/09185065803
- Category: Connectors
- Series: SEK
- Element: Female connector
- Connection type: PCB to cable
- Number of contacts: 6
- Pitch: 1.27 mm
- AWG: 28/7 - 26/7
- Contact rows: 2
- Contact spacing (termination side): 2.54 mm
- Contact spacing (mating side): 1.27 mm
- Rated current: 2.5 A
- Insulation resistance: >10 Ω
- Contact resistance: ≤20 mΩ
- Limiting temperature: -55 ... +125 °C
- Insertion and withdrawal force: ≤12 N
- Performance level: NM 30 (S4)
- Mating cycles: ≥250
- Test voltage Ur.m.s.: 1 kV
- Material (insert): Thermoplastic resin (PBT)
- Colour (insert): Grey
- Material (contacts): Copper alloy
- Surface (contacts - Matingside): Noble metal over Ni
- Surface (contacts - Termination side): Sn over Ni
- Layer thickness: ≥0.76 µm
- Layer thickness (inch): ≥30 µinch
- Flammability class: V-0
- RoHS: compliant
- ELV status: compliant
- China RoHS: e
- REACH Annex XVII substances: Not contained
- REACH ANNEX XIV substances: Not contained
- REACH SVHC substances: Not contained
- California Proposition 65 substances: Yes
- California Proposition 65 substances (details): Antimonytrioxide, Nickel
- Specifications (IEC): IEC 60603-13
- UL / CSA: UL 1977 ECBT2.E102079, CSA-C22.2 No. 182.3 ECBT8.E102079
- Railway classification: F3/I3
- Packaging size: 100
- Net weight: 1.014 g
- Country of origin: Romania
- European customs tariff number: 85366990
- eCl@ss: 27460202
