Harting 09185606914 PCB Connector
The SEK-18 SV MA STD STR29 RKZ 60P connector is a PCB-mount, straight connector designed for reliable signal and power transmission. It features wave soldering termination with a connection type suitable for PCB to cable applications, supporting up to 60 contacts. Made from thermoplastic resin (PBT) with copper alloy contacts, it offers high insulation resistance, rated current of 1A, and a temperature range from -55°C to +125°C. The connector ensures compliance with UL, CSA, IEC standards, and RoHS, suitable for demanding electrical and industrial applications.
Harting 09185606914 PCB Connector Specifications:
- Material (body): Thermoplastic resin (PBT)
- Material (contacts): Copper alloy with noble metal over Ni
- Surface (contacts): Sn over Ni
- Color: Grey
- Number of contacts: 60
- Connection type: PCB to cable
- Termination method: Wave soldering
- Termination length: Not specified
- Contact spacing: 2.9mm
- Rated current: 1A
- Insulation resistance: >10 MΩ
- Contact resistance: <20mΩ
- Limiting temperature: -55°C to +125°C
- Mating cycles: 2000
- Performance level: IEC 60603-13
- Locking type: With short levers
- Insert and withdrawal force: <120N
- Test voltage: 1kV
- UL/CSA: Compliant
- RoHS: Compliant
- Flammability: V-0
- Net weight: 12.64g
- Country of origin: Romania
- Packaging size: Not specified
Buy the Buy HARTING SEK-18 SV MA STD STR29 RKZ 60P Part Number 09185606914 Online
Enhance your electronic assembly with the HARTING PCB connector, featuring 60 contacts, wave soldering compatibility, and robust materials that operate reliably from -55°C to +125°C. This straight connector ensures secure connections for industrial, automation, and signal transmission applications. Made with thermoplastic resin and copper alloy contacts, it provides excellent contact resistance, insulation resistance, and compliance with international standards like UL and IEC. Easily install and maintain high electrical performance with this durable, RoHS-compliant board connector.
Buy HARTING SEK-18 SV MA STD STR29 RKZ 60P now and experience unmatched reliability and high-performance electrical connectivity.
Frequently Asked Questions
Where can I buy Harting 09185606914?
You can click on the BUY or RFQ button to purchase 09185606914 from an authorized Harting distributor.
How do I troubleshoot issues or seek technical support for part 09185606914?
You can download the 09185606914 datasheet or visit the Harting website for support.
Who is the manufacturer of 09185606914?
Harting
