Harting 21033961533 PCB Power Connector
The HARTING PCB housing and back insert are designed for rear mounting applications, providing reliable connections with screw locking and shielded features. Made with robust zinc die-cast housing and gold-plated copper contacts, it supports reflow soldering termination and is suitable for PCB adapters. This connector withstands up to 16A current, 63V voltage, and a peak impulse of 1.5kV, operating efficiently within -40°C to +85°C. It offers over 2100 mating cycles, ensuring durability in industrial environments, certified per IEC standards, and complying with safety and quality regulations.
Harting 21033961533 PCB Power Connector Specifications:
- Rated current: 16A
- Rated voltage: 63V
- Rated impulse voltage: 1.5kV
- Ambient temperature: -40°C to +85°C
- Mating cycles: 2100
- Pollution degree: >10°
- Contact resistance: 10 mΩ
- Material (contacts): Copper alloy with gold plating
- Material (housing): Zinc die-cast
- Material (insert): PA (Polyamide)
- Surface (contacts): Gold-plated
- Insulation resistance: >10 GΩ
- Insulation group: (600 < CTI)
- Certification: IEC 61076-2-111
- Packaging size: 1 piece
- Net weight: 31g
- Country of origin: Romania
Buy the Buy HARTING PCB Power Connector Part Number 21033961533 Online
Purchase the HARTING PCB housing and back insert online to enjoy reliable rear mounting connections, robust zinc die-cast construction, gold-plated contacts, and high durability. Designed for industrial applications, it supports reflow soldering termination and withstands up to 16A current and 63V voltage. With over 2100 mating cycles and IEC certification, this connector ensures long-lasting performance and safety, making it an ideal choice for professional electronic and automation systems. Order now for quick, secure online delivery.
Buy HARTING 21033961533 PCB housing now and ensure secure, reliable PCB connections with high mating cycle durability and electrical safety.
Frequently Asked Questions
Where can I buy Harting 21033961533?
You can click on the BUY or RFQ button to purchase 21033961533 from an authorized Harting distributor.
How do I troubleshoot issues or seek technical support for part 21033961533?
You can download the 21033961533 datasheet or visit the Harting website for support.
Who is the manufacturer of 21033961533?
Harting
