HIROSE(HRS) TM21P88P17 LAN Modular Plug
The TM21P Series modular plug connectors are designed for high-speed LAN transmission, supporting Gigabit Ethernet and Fast Ethernet standards. Shielded and non-shielded types ensure EMI protection and reliable connections for telecommunications, networking, and testing equipment. The shielded version features 360° coverage, protected latch tabs, and simplified termination for ease of use. Compliant with TIA/EIA-568B and ISO 8877 standards, these connectors deliver excellent electrical performance, durability, and compatibility with Category 5 standards. Suitable for telecom hubs, routers, switches, and industrial applications requiring robust and high-performance cabling solutions.
HIROSE(HRS) TM21P88P17 LAN Modular Plug Specifications:
- Current rating: 1A
- Voltage rating: 125 VAC
- Operating temperature range: -25°C to +60°C
- Insulation resistance: 100 M ohms min. at 100 V DC
- Withstanding voltage: 500 V AC for 1 min (adjacent contacts), 1500 V AC for 1 min (contact to shield)
- Contact resistance: 230 m ohms max; durability: 200 mating cycles
- Materials: Copper alloy contacts with gold plating, copper shield Tin-plated
- Conductor compatibility: Solid or stranded copper conductors AWG #24
- Cable jacket diameter: Shielded cable 6.6 mm, Non-shielded cable 5.4–5.7 mm
- Connector dimensions: Shielded - approximately 29.5 mm length; Non-shielded - approximately 11.85 mm length
- Complies with TIA/EIA-568B, ISO 8877
- Shielded version supports EMI protection with 360° coverage, shield connected securely
- Supports Category 5e transmission characteristics with low attenuation, NEXT, FEXT, return loss, and propagation delay specifications
- Applicable for telecom, networking, and industrial applications requiring reliable high-speed data transmission
Buy the Hirose Series TM21P LAN Connector: TM21P-88P
Purchase Hirose TM21P-88P modular plug connectors online today for high-performance LAN connections. Designed for Gigabit Ethernet and Fast Ethernet, these shielded or non-shielded connectors offer excellent EMI protection, durability, and easy termination. Implemented in telecom hubs, routers, and industrial networking equipment, they ensure reliable data transfer with low attenuation, minimal crosstalk, and compliance with Category 5 standards. Enjoy fast, secure online shopping and equip your network setup with connectors engineered for longevity and superior performance.
Get Hirose TM21P-88P today—built for high-speed LAN connections and reliable EMI protection in demanding network environments.
Frequently Asked Questions
Where can I buy HIROSE(HRS) TM21P88P17?
You can click on the BUY or RFQ button to purchase TM21P88P17 from an authorized HIROSE(HRS) distributor.
How do I troubleshoot issues or seek technical support for part TM21P88P17?
You can download the TM21P88P17 datasheet or visit the HIROSE(HRS) website for support.
Who is the manufacturer of TM21P88P17?
HIROSE(HRS)
