Honeywell FSAGPNXX003LCAC5 Force Sensor
The FSA Series force sensors are piezoresistive, calibrated, and temperature-compensated for accurate force measurement over a wide range. They offer analog and digital outputs, with selectable force ranges from 5N to 25N, or 1lb to 5lb. Designed for medical and industrial applications, these sensors feature durable construction, internal diagnostics, and stable interfaces. They operate efficiently within a temperature range of 5°C to 50°C, consume low power, and are compliant with industry standards for reliability and performance, providing precise force sensing with enhanced durability in demanding environments.
Honeywell FSAGPNXX003LCAC5 Force Sensor Specifications:
- Supply Voltage: 3.3 Vdc typ. or 5.0 Vdc typ.
- Supply Current: 13 mW at 3.3 V, 20 mW at 5 V
- Operating Temperature Range: 5°C to 50°C
- Storage Temperature Range: -40°C to 85°C
- Force Ranges: 5N, 7.5N, 10N, 15N, 20N, 25N, 1lb, 1.5lb, 2lb, 3lb, 5lb
- Total Error Band: ±5%FSS, Accuracy: ±3%FSS
- Response Time: 1 ms (digital), 0.42-0.84 ms (analog)
- Protection: ESD susceptibility 2 kV, overforce limit 6804 g
- Materials: Cover high-temp polyamide, plunger stainless steel 316
- Life Cycle: Minimum 1 million full scale force cycles
- Dimensions: Mounting dimensions approx. 25 mm x 23.6 mm, height varies
- Communication: SPI, I2C digital outputs, analog output available
- Compliance: RoHS, REACH
Buy the Buy Honeywell Force Sensors Part Number FSAGPNXX003LCAC5 Online
Purchase Honeywell Force Sensors online today and benefit from accurate force measurement, durable construction, and flexible output options. Designed for demanding medical and industrial environments, these sensors provide stability, low power consumption, and built-in diagnostics for easy maintenance. Their wide temperature range and high cycle life ensure long-lasting performance. Whether for infusion pumps, load sensing, or compression detection, buying these sensors online guarantees quick delivery and reliable, industry-approved quality for safe and precise force measurement in your application.
Buy Honeywell FSAGPNXX003LCAC5 now and experience unmatched reliability and precise force sensing for industrial and medical applications.
Frequently Asked Questions
Where can I buy Honeywell FSAGPNXX003LCAC5?
You can click on the BUY or RFQ button to purchase FSAGPNXX003LCAC5 from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part FSAGPNXX003LCAC5?
You can download the FSAGPNXX003LCAC5 datasheet or visit the Honeywell website for support.
Who is the manufacturer of FSAGPNXX003LCAC5?
Honeywell
