Honeywell HAFUHM0010L4AXT Digital Airflow Sensor
Honeywell Zephyr™ HAF Series airflow sensors provide high-accuracy digital measurement for precise airflow detection in medical and industrial applications. They feature fast response times of 1 ms, wide flow ranges from 10 SLPM to 300 SLPM, and onboard ASIC calibration with I2C digital output, making them ideal for demanding environments like anesthesia equipment, fume hoods, and process controls. Rugged, reliable, and customizable, these sensors ensure repeatable, stable measurements while reducing system size and complexity, complying with RoHS standards for environmentally conscious design.
Honeywell HAFUHM0010L4AXT Digital Airflow Sensor Specifications:
- Supply voltage: 3Vdc to 10 Vdc
- Supply current: 20 mA max.
- Power: 3 Vdc 60 mW max., 10 Vdc 200 mW max.
- Calibrated temperature range: 0°C to 50°C
- Operating temperature: -20°C to 70°C
- Full scale flow: 10 to 300 SLPM
- Flow response time: 1 ms
- Resolution: 10 SLPM 0.002 SLPM, 15 SLPM 0.003 SLPM, 20 SLPM 0.003 SLPM, 50 SLPM 0.008 SLPM, 100 SLPM 0.015 SLPM, 200 SLPM 0.029 SLPM, 300 SLPM 0.043 SLPM
- Max burst pressure: 13.7 bar
- Max proof pressure: 10.3 bar
- Humidity: 0% to 95% RH, non-condensing
- Shock: 30g, 6ms
- Vibration: 1.33 g at 10-500 Hz
- Materials: glass reinforced thermoplastic, gold, silicon, silicon dioxide and nitride, epoxy
- Mounting: screw size 10-32, torque 1.13 N·m
- Connections: manifold mount, 22 mm OD tapered or G 3/8 threaded
- Compliance: RoHS, WEEE.
Buy the Buy Honeywell HAF Series Digital Airflow Sensors Part Number HAFUHM0010L4AXT Online
Discover the reliable performance of Honeywell HAF Series digital airflow sensors. With fast response times of 1 ms, wide flow ranges, onboard calibration, and robust construction, these sensors are perfect for demanding applications in medical and industrial environments. Their I2C digital interface, high stability, and customizable options make integration simple and efficient. Purchase online today to enhance your system’s accuracy, reduce design complexity, and meet stringent quality standards with Honeywell’s proven sensing technology and support.
Order your Honeywell HAF Series airflow sensor today and ensure precise airflow measurement for medical, industrial, and process control applications.
Frequently Asked Questions
Where can I buy Honeywell HAFUHM0010L4AXT?
You can click on the BUY or RFQ button to purchase HAFUHM0010L4AXT from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part HAFUHM0010L4AXT?
You can download the HAFUHM0010L4AXT datasheet or visit the Honeywell website for support.
Who is the manufacturer of HAFUHM0010L4AXT?
Honeywell
