Honeywell PX2EN1XX250PSAAX Heavy Duty Pressure Transducer
Honeywell’s PX2 Series Heavy Duty Pressure Transducer provides a portfolio of highly configurable pressure sensors utilizing piezoresistive sensing technology and ASIC signal conditioning. Fully calibrated and compensated, it delivers a Total Error Band of ±2% across a temperature range of -40°C to 125°C. With thousands of configurations, the PX2 Series caters to diverse industrial applications, including HVAC/R systems, air compressors, and factory automation. Its robust design, wide operating temperature range, and ingress protection up to IP69K ensure reliable performance in demanding environments. The transducer is RoHS compliant and manufactured according to ISO 9001 standards, offering affordability, availability, high performance, and durability.
Honeywell PX2EN1XX250PSAAX Heavy Duty Pressure Transducer Specifications:
- Pressure Range: 1 bar to 46 bar, 100 kPa to 4.6 MPa, 15 psi to 667 psi
- Total Error Band: ±2%
- Operating Temperature Range: -40 °C to 125 °C [-40 °F to 257 °F]
- Connector Types: Delphi Metri-Pack 150, Micro M12, DIN, Deutsch, cable harness (1 m, 2 m, 3 m, or 5 m)
- Port Types: 1/4-18 NPT, 1/8-27 NPT, 9/16-18 UNF SAE J1926-3, 7/16-20 UNF SAE J1926-3, 1/4 in 45° Flare Female Schrader (7/16-20 SAE J512), M12 x 1.5 ISO 6149-3, G1/4 ISO 1179-3, G1/8 ISO 1179-3
- Pressure Reference: Absolute or sealed gage
- Output Transfer Function: Ratiometric, regulated or current
- Mechanical Shock Rating: 100 G per MIL-STD-202F, Method 213B, Cond. F
- Vibration Rating: 20 G sweep, 10 Hz to 2000 Hz
- Ingress Protection: Up to IP69K
- Radiated Immunity: 100 V/m
Buy the PX2EN1XX250PSAAX HONEYWELL Heavy Duty Pressure Transducer | myMectronic
Purchase the Honeywell PX2EN1XX250PSAAX Pressure Transducer securely and efficiently through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy Honeywell PX2EN1XX250PSAAX?
You can click on the BUY or RFQ button to purchase PX2EN1XX250PSAAX from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part PX2EN1XX250PSAAX?
You can download the PX2EN1XX250PSAAX datasheet or visit the Honeywell website for support.
Who is the manufacturer of PX2EN1XX250PSAAX?
Honeywell
