Hammond Manufacturing 1182S24 Datasheet & Stock
The 1182S24 is a toroidal power transformer designed for industrial applications. Constructed with class B insulating material, it features dual primary windings compatible with 117/234V AC and dual secondary windings. The compact and lightweight design ensures efficient operation with low heat generation and minimal electromagnetic interference due to low magnetic flux diffusion. It is rated for operation at 50/60Hz and includes conductors of at least 8 inches in length. The transformer has undergone dielectric testing at 4000VAC RMS between primary and secondary windings and complies with UL 506 (E207860), CSA Standard C22.2 No. 66-209651, and IEC standard 61558-2-4. The package includes the transformer, rubber washers, a steel mounting washer, a bolt with lockwasher, and a hex nut, making installation straightforward.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 1182S24?
You can click on the BUY or RFQ button to purchase 1182S24 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 1182S24?
You can download the 1182S24 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 1182S24?
Hammond Manufacturing
