Hammond Manufacturing 1598ASGY Instrument Case
The Hammond 1598A Instrument Case features a sturdy aluminum enclosure with black plastic panels, rubber feet, and cover screws. Designed for electronic and industrial applications, it includes top and bottom covers, aluminum front and end panels, and accommodates a maximum printed circuit board size of approximately 147 mm in length and 123 mm in width. The case offers factory modifications like milling and drilling, with solid models available in STEP or IGES formats. It ensures durability, precise assembly, and ease of customization for various instrumentation needs.
Hammond Manufacturing 1598ASGY Instrument Case Specifications:
- Enclosure Material: Aluminum alloy 5052-H32 with SPV coating on one side
- Panel Material: Black plastic panels
- Maximum P.C. Board Size: 147 mm length x 123 mm width (approximate)
- Inner Box Length: 145.70 mm
- Inner Box Height: 29.50 mm
- Inner Box Width: 123.1 mm
- Outer Dimensions: Front face 156.50 mm wide, depth 81.90 mm, end panel 35.00 mm wide
- Side View Inside Assembly: Bosses at 2.18 mm separation, with P.C. board aligned on bosses
- Additional Features: Factory modifications available (milling, drilling, printing), includes rubber feet and cover screws
- Design includes viewing area, internal bosses for PCB mounting, and options for custom modifications in STEP or IGES formats.
Buy the Hammond Series Instrument Case: 1598A
Order the Hammond 1598A instrument case online now to ensure reliable protection for your electronic components. This enclosure features durable aluminum construction with black plastic panels, rubber feet, and versatile factory modifications like milling and drilling. It is designed to accommodate printed circuit boards up to approximately 147 mm long and 123 mm wide, providing precise internal mounting features and a viewing area. Perfect for industrial applications, its robust construction and customizable options make it an ideal choice for engineers requiring durable and adaptable enclosures for sensitive electronics.
Get Hammond 1598A instrument case today—built for precision, durability, and easy customization for your electronic projects.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 1598ASGY?
You can click on the BUY or RFQ button to purchase 1598ASGY from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 1598ASGY?
You can download the 1598ASGY datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 1598ASGY?
Hammond Manufacturing
