Hammond Manufacturing 160D12 Low Voltage Transformer
The 160D12 is a 1 VA low-voltage PCB-mounted isolation transformer designed for applications requiring electrical isolation and voltage conversion. It features a dual primary of 115/230V at 50/60Hz, a split bobbin vertical-mount design, and non-concentrically wound secondary windings. The transformer provides a 12.6V center-tapped output at 70mA when series-connected and 6.3V at 140mA when parallel-connected. It offers low primary-to-secondary coupling, high insulation with a 2000 Vrms Hi-pot test, and Class-B insulation rated at 130°C. Suitable for power management and industrial applications.
Hammond Manufacturing 160D12 Low Voltage Transformer Specifications:
- Power Rating: 1 VA
- Primary Voltage: 115/230V at 50/60Hz dual primary
- Secondary Voltage: 12.6V center-tapped at 70mA (series), 6.3V at 140mA (parallel)
- Construction: Split bobbin, vertical mount, non-concentrically wound windings
- Insulation: Class B rated at 130°C
- Insulation Strength: High insulation with 2000 Vrms Hi-pot test
- Coupling: Low primary to secondary coupling, no electrostatic shield required
- Dimensions: Compact size suitable for PCB mounting
- Applications: Power management, industrial control, signal isolation
Buy the Hammond Series Low Voltage Transformer: 160D12
Purchase the Hammond Series low voltage PCB-mounted isolation transformer 160D12 online today. Designed for reliable electrical isolation, it features a dual primary of 115/230V, a split bobbin vertical mount, and non-concentrically wound secondary windings providing 12.6V or 6.3V outputs at appropriate current ratings. Its high insulation with a 2000 Vrms Hi-pot and Class-B insulation rated at 130°C ensure safety and durability for industrial, power management, and control applications. Buy now for efficient, safe, and dependable operation.
Order your Hammond SeriesLow Voltage Transformer 160D12 today and give your industrial power supplies the dependable quality they deserve.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 160D12?
You can click on the BUY or RFQ button to purchase 160D12 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 160D12?
You can download the 160D12 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 160D12?
Hammond Manufacturing
