Hammond Manufacturing 160E28 Power Transformer
The 160E28 power transformer is ideal for power management and industrial applications, delivering reliable performance with dual primary options of 115/230V and various secondary voltages. It features a split bobbin, high insulation of 2000V RMS, and Class B insulation rated at 130°C. Available in 10 VA size, it offers excellent electrical isolation, low coupling, and CSA and UL certifications, making it suitable for commercial and industrial control systems requiring stable, efficient voltage transformation with high safety standards.
Hammond Manufacturing 160E28 Power Transformer Specifications:
- Power Rating: 10 VA
- Primary Voltage: 115V or 115/230V dual primary options
- Secondary Voltages: 10VCT@1A, 5V@2A
- Insulation: High insulation - Hipot of 2000V RMS, Class B insulation at 130°C
- Mounting: Vertical mount, split bobbin design
- Winding: Dual winding secondaries, non-concentrically wound
- Size: Overall dimensions approximately 1.94 x 1.44 x 1.69 inches
- Construction: Encapsulated for rugged industrial environments
- Certifications: CSA certified (LR3902), UL recognized (E50394)
- Temperature Rating: 130°C
- Efficiency: Suitable for power management with stable voltage output
- Protection: Low primary to secondary coupling, no electrostatic shield required
Buy the Hammond Series 160E28 Power Transformer: 10 VA Dual Primary 115/230V
Purchase the Hammond Series 160E28 power transformer online now for your industrial projects. Designed for power management with dual primary options and 10 VA capacity, this reliable component offers high insulation, safety certifications, and rugged construction. Its compact size fits various control panels, providing stable voltage transformation essential for industrial and commercial applications. Trust Hammond’s quality and get quick delivery to enhance your power supply stability and operational efficiency with this high-performance transformer.
Order your Hammond Series 160E28 power transformer today and ensure your industrial control systems operate with dependable, high-quality voltage conversion.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 160E28?
You can click on the BUY or RFQ button to purchase 160E28 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 160E28?
You can download the 160E28 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 160E28?
Hammond Manufacturing
