Hammond Manufacturing 162F12 Datasheet & Stock
The 162F12 is a 6VA low-voltage PCB-mounted isolation transformer designed for power management and industrial applications. It features dual primary windings compatible with 115V or 230V mains, operating at 50/60Hz. The transformer has a split bobbin design with non-concentrically wound secondary coils, which must all be utilized. It provides a 12.6V center-tapped secondary at 0.5A in series connection or 6.3V at 1A in parallel, with low primary to secondary coupling and no electrostatic shield required. The unit offers high insulation with a 2500V RMS dielectric strength and is rated with Class B insulation at 130°C temperature.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 162F12?
You can click on the BUY or RFQ button to purchase 162F12 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 162F12?
You can download the 162F12 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 162F12?
Hammond Manufacturing
