Hammond Manufacturing 162J28 Datasheet & Stock
The 162J28 is a 36 VA low-voltage PCB-mount isolation transformer designed for power management and industrial applications. It features a dual primary of 115/230V operating at 50/60Hz, and a low-profile split bobbin construction with non-concentrically wound secondary windings that must all be used. The transformer provides a 28V center-tapped secondary at 1.3A series or 14V at 2.6A parallel (RMS). It offers low primary-to-secondary coupling without the need for an electrostatic shield, a high dielectric strength with a 2500 Vrms Hi-pot rating, and Class-B insulation rated for 130°C.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 162J28?
You can click on the BUY or RFQ button to purchase 162J28 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 162J28?
You can download the 162J28 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 162J28?
Hammond Manufacturing
