Hammond Manufacturing 164E20 Industrial Power Transformer
This component is used in power management and industrial applications. It is a low profile, split bobbin transformer available in multiple voltages and power sizes, designed for PCB mounting with industry-standard pin spacing. It features dual winding secondaries, high insulation of 2,500V RMS Hipot, and class B insulation rated at 130°C, suitable for various voltages from 5V to 48V with different current capacities. It operates efficiently on 50/60 Hz power supplies, providing reliable performance in industrial projects.
Hammond Manufacturing 164E20 Industrial Power Transformer Specifications:
- Power sizes: 1.1 to 36VA
- Voltages: 5V to 48V secondary, 115V or 115/230V primary
- Frequency: 50/60 Hz operation
- High insulation: 2,500V RMS Hipot
- Insulation Class: B, rated at 130°C
- Mounting: PCB with industry-standard pin spacing, no hardware on smaller sizes, four-hole mounting on larger models
- Winding: Dual secondary, non-concentrically wound, all windings must be used
- Design: Split bobbin, low profile, dual winding secondary
- Operating conditions: Designed for reliable industrial and power management applications
- Dimensions: Varies by model, typical length ~1.38 to 2.63 inches, height ~0.25 to 1.56 inches
- Weight: Ranges from 0.17 to 1.1 pounds depending on size
- Certifications: UL and UL recognized
Buy the Hammond 164E20 – Reliable Power Transformer for Industrial Applications
Enhance your industrial projects with the Hammond Series 164E20 power transformer. Designed for PCB mounting, this reliable, high-insulation component offers various voltage options from 5V to 48V with sufficient current ratings. Manufactured with high-quality materials and UL recognized standards, it ensures durability and consistent performance. Ideal for power supplies, automation, and control systems, this transformer is available for easy online purchase, providing fast delivery, superior quality, and the support you need for your industrial applications.
Order your Hammond Series 164E20 industrial power transformer today and ensure your power management projects benefit from dependable, high-quality performance.
