Hammond Manufacturing 186B10 Industrial Transformer
This component is designed for industrial applications, offering reliable performance in demanding environments. Suitable for use in various industrial equipment and systems.
Hammond Manufacturing 186B10 Industrial Transformer Specifications:
- Primary voltage: 115VAC or 115/230VAC depending on series
- Secondary voltage: 10V C.T.
- Current: 0.6 Amps
- VA Rating: 6 VA
- Dimensions: Length 2.37 inches, Height 1.25 inches, Mounting centers 2.00 inches, Depth 1.37 inches
- Construction: Split bobbin eliminates need for electrostatic shield
- Insulation: Class B, 130°C
- Temperature rise: Designed to Class A
- Terminals: 3/16 (.187) quick connect or solder lug terminals
- Testing: Hi-pot tested to 2 KV RMS
- Certification: UL recognized, CSA certified
Buy the Hammond Series 187 Industrial Transformer: 186B10
Order the Hammond 186B10 industrial transformer online today to ensure reliable power conversion for demanding industrial environments. Designed with split bobbin construction, it eliminates the need for electrostatic shields and is UL recognized and CSA certified. Perfect for various equipment, it supports 115VAC primary voltage with a 6 VA rating, and features optional quick connect or solder lug terminals. With tests to 2 KV RMS and Class B insulation, this transformer guarantees performance, safety, and durability in your industrial applications.
Get Hammond 186B10 today—built for industrial reliability and long-lasting performance.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 186B10?
You can click on the BUY or RFQ button to purchase 186B10 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 186B10?
You can download the 186B10 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 186B10?
Hammond Manufacturing
