Hammond Manufacturing 186C12 Industrial Transformer
This high-quality industrial transformer is designed for reliable voltage conversion in industrial environments. It features a dual primary voltage option of 115/230VAC, split bobbin construction that eliminates the need for an electrostatic shield, and UL recognition with CSA certification. It operates on 50/60 Hz, has a maximum insulation temperature of 130°C, and is tested to 2 kV RMS high potential. Its open style, chassis-mount design ensures easy installation, making it ideal for powering various industrial equipment with efficient and safe voltage transformation.
Hammond Manufacturing 186C12 Industrial Transformer Specifications:
- Primary Voltage: 115/230 VAC, dual primary
- Secondary Voltage: 12.6V C.T.
- Current Rating: 1 A
- Power Rating: 15.8 VA
- Frequency: 50/60 Hz
- Insulation Material: Class B (130°C)
- Construction: Split bobbin
- Testing: Hi-pot tested to 2 KV RMS
- Mounting: Chassis mount
- Dimensions: Length 2.81 inches, Height 1.62 inches, Depth 1.37 inches
- Terminals: 3/16 (.187) Quick Connect, Solder Lug
- Certification: UL Recognized, CSA Certified
Buy the Hammond 186C12 – Reliable Transformer for Industrial Applications
Enhance your industrial setup with the Hammond 186C12 transformer, designed for dependable voltage conversion. Featuring dual primary 115/230VAC, UL recognition, CSA certification, split bobbin construction, and high insulation standards, it provides safe, efficient operation. Its open chassis mount design allows easy installation in various industrial environments. Tested to 2 kV RMS high potential, ensuring safety and durability. Ideal for powering industrial equipment reliably, it is a cost-effective solution to meet your voltage transformation requirements. Order online today for quick delivery and exceptional performance.
Buy Hammond 186C12 now and experience unmatched reliability and performance for your industrial voltage conversion needs.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 186C12?
You can click on the BUY or RFQ button to purchase 186C12 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 186C12?
You can download the 186C12 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 186C12?
Hammond Manufacturing
