Hammond Manufacturing 186C120 Industrial Transformer
This component is designed for industrial equipment, featuring dual primary voltage options of 115/230 V and multiple secondary voltage configurations. It includes a split bobbin construction that eliminates the need for an electrostatic shield, ensuring reliable performance across applications. Hi-pot tested to 2 KV RMS for safety. The open style, channel frame chassis mount provides easy installation, and the insulation material is rated at Class B or 130 degrees Celsius, designed to meet Class A temperature rise standards. UL recognition and CSA certification ensure compliance and safety in demanding industrial environments.
Hammond Manufacturing 186C120 Industrial Transformer Specifications:
- Primary Voltage: 115/230 VAC dual primary options
- Secondary Voltage: Various configurations including 10V, 12.6V, 16V, 20V, 24V, 28V, 36V, 48V, 56V, 120V
- Rated Current: From 0.05 A to 10 A depending on model
- Power Rating: Up to 120 VA
- Construction: Split bobbin design eliminates need for electrostatic shield
- Insulation Material: Rated at Class B or 130°C
- Temperature Rise: Designed for Class A
- Testing: Hi-pot tested at 2 KV RMS
- Mounting: Chassis mount with 3/16 inch quick connect or solder lug terminals
- Dimensions: Length varies from approximately 2.06 to 4.03 inches, height around 1.06 to 2.25 inches, mounting centers vary
- Standards: UL Recognized and CSA Certified
Buy the Hammond 186C120 – Reliable Industrial Transformer for Power Supply Applications
Purchase the Hammond 186C120 industrial transformer online today to ensure reliable power supply in your industrial systems. Featuring dual primary voltage options and multiple secondary configurations, this transformer guarantees performance in demanding environments. Its open style chassis mount, split bobbin construction, and UL/CSA certification offer safety and ease of installation. Designed for a 130°C insulation rating and tested at 2 KV RMS, it ensures long-term durability and safety. Ideal for automation, control panels, and power distribution in industrial settings—order now for quick delivery and guaranteed quality.
Get Hammond 186C120 today—built for precision, safety, and long-lasting durability in industrial applications.
