Hammond Manufacturing 186C20 Low Voltage Transformer
The Hammond 186C20 is an open style, chassis-mounted low voltage transformer suitable for various industrial applications. It features a split bobbin construction eliminating the need for electrostatic shields and is Hi-pot tested to 2 KV RMS for safety and reliability. Designed for 115/230 VAC dual primary operation and 50/60 Hz frequency, it offers durable solder or quick connect terminals. UL recognized and CSA certified, this economical transformer suits control systems, automation, and power distribution needs with its robust construction and multiple voltage options.
Hammond Manufacturing 186C20 Low Voltage Transformer Specifications:
- Type: Low Voltage Open Style Chassis Mount
- Series: 186 / 187 series
- Primaries: Single 115VAC or Dual 115/230VAC, 50/60 Hz operation
- Terminals: Combination solder or quick connect
- Construction: Split bobbin, eliminating electrostatic shield need
- Testing: Hi-pot tested to 2 KV RMS
- Certifications: UL recognized, CSA certified
- Mounting: Economical channel frame, chassis mount
- Operating Frequency: 50/60 Hz
- Approximate Dimensions (Inches): Length: 2.34-6.40, Depth: 1.06-2.25, Height: 1.75-3.50, Centers to Terminal: 1.435-2.625
Buy the Hammond Series 186 Low Voltage Open Style Chassis Mount: 186C20
Purchase the Hammond 186C20 low voltage chassis mount transformer online today and benefit from a reliable, UL recognized power solution suitable for various industrial controls. Its split bobbin construction, dual primary options, and 2 KV Hi-pot testing ensure safe operation and durability. Designed for 115/230 VAC operation and 50/60 Hz frequency, it offers easy installation with solder or quick connect terminals. Ideal for automation, control panels, and power distribution, this economical transformer provides performance efficiency and meets safety standards for industrial environments.
Buy Hammond 186C20 now and experience unmatched reliability and high-quality performance for industrial control and automation projects.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 186C20?
You can click on the BUY or RFQ button to purchase 186C20 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 186C20?
You can download the 186C20 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 186C20?
Hammond Manufacturing
