Hammond Manufacturing 186E24 Low Voltage Transformer
The 186E24 is a low-voltage open-style chassis-mount transformer designed for versatile applications in electronic equipment. It features split bobbin construction, eliminating the need for an electrostatic shield, and is Hi-pot tested to 2 KV RMS for safety and reliability. With dual primary options of 115/230 VAC operating at 50/60 Hz, it offers multiple secondary voltage configurations including 24VCT. Its economical open-frame design ensures easy installation in industrial control, automation, and electrical systems, and it’s UL recognized and CSA certified for quality assurance.
Hammond Manufacturing 186E24 Low Voltage Transformer Specifications:
- Input Voltage: 115/230 VAC, 50/60 Hz
- Secondary Voltage: 24VCT RMS
- Transformer Type: Open style, chassis mount
- Construction: Split bobbin design eliminates need for electrostatic shield
- Hi-pot Testing: 2 KV RMS
- Certification: UL recognized, CSA certified
- Mounting: Chassis mount, channel frame
- Temperature Rating: Not specified but typically -55°C to +105°C
- Dimensions: Length 2.81-4.03 inches, Width 1.37-2.25 inches, Height 1.62-2.56 inches (varies by model)
- Terminals: Combination solder or quick connect terminals
Buy the Hammond Series 186E24 Low Voltage Transformer: 186E24
Purchase the Hammond 186E24 low-voltage transformer online to ensure your electronic projects and control systems operate reliably. Designed with split bobbin construction, it offers versatility with dual primary options of 115/230 VAC and a 24V secondary, making it suitable for various industrial applications. Its chassis mount open-frame design simplifies installation, and being UL recognized and CSA certified guarantees safety and quality. Hi-pot tested to 2 KV RMS, this economical transformer is an excellent choice for durable, high-performance electrical systems.
Get Hammond 186E24 today—built for reliable power conversion in industrial automation and electrical applications.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 186E24?
You can click on the BUY or RFQ button to purchase 186E24 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 186E24?
You can download the 186E24 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 186E24?
Hammond Manufacturing
