Hammond Manufacturing 186F10 Power Transformer
This power transformer offers versatile primary options of 115VAC or 115/230VAC, with split bobbin construction that eliminates the need for an electrostatic shield. It features solder or quick connect terminals for easy wiring, is Hi-pot tested at 2 KV RMS for safety, and complies with UL and CSA certifications. Designed for economical chassis mounting, it operates at Class B insulation temperatures up to 130°C, with a temperature rise-rated construction suitable for industrial power management and control systems in demanding environments.
Hammond Manufacturing 186F10 Power Transformer Specifications:
- Primary Voltage Options: 115VAC or 115/230VAC
- Secondary Voltage Options: 10V, 12.6V, 16V, 20V, 24V, 28V, 36V, 48V, 56V, 120V
- Current Ratings: Ranging from 0.19A to 18A depending on model
- Power Rating: From 6 VA up to 612 VA
- Construction: Split bobbin design eliminating electrostatic shield
- Terminals: Solder lug or quick connect, 3/16 (.187) diameter
- Dimensions: Length approximately 2.06-4.03 inches, Height 1.06-2.25 inches, Hole centers 1.75-3.50 inches
- Insulation Material: Minimum Class B or 130°C rated
- Operating Frequency: 50/60 Hz
- Test Standards: Hi-pot tested at 2 KV RMS
- Certifications: UL Recognized, CSA Certified
Buy the Hammond Series 187 Power Transformer: 186F10
Purchase the Hammond 186F10 power transformer online today for your industrial and power management needs. Designed with dual primary options and quick connect terminals, it offers reliable performance in demanding environments. UL recognized and CSA certified for safety and quality, this transformer features split bobbin construction that eliminates the need for electrostatic shields. It operates at Class B insulation temperature up to 130°C, making it ideal for control panels, automation systems, and industrial control applications requiring efficient power conversion and consistent durability.
Get Hammond 186F10 today—built for reliable power management and industrial control applications.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 186F10?
You can click on the BUY or RFQ button to purchase 186F10 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 186F10?
You can download the 186F10 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 186F10?
Hammond Manufacturing
