Hammond Manufacturing 186F36 Power Transformer
This component is designed for power management applications in industrial environments, providing reliable power regulation and control solutions.
Hammond Manufacturing 186F36 Power Transformer Specifications:
- Primary Voltage: 115 V or 115/230 V
- Secondary Voltage: 36 VCT
- Current Rating: 2.8 Amps
- VA Rating: 100.8 VA
- Insulation Material: Min. Class B or 130°C
- Operating Frequency: 50/60 Hz
- Construction: Split bobbin, open style, chassis mount
- Dimensions: Length approximately 4.03 inches, height 2.25 inches, terminal centers 2.56 inches
- Terminals: 3/16 (.187) quick connect or solder lug
- Temperature Rating: Designed to Class A temperature rise
- Hi-pot Test Voltage: 2 KV RMS
- Certifications: UL recognized, CSA certified
Buy the Buy Hammond Power Transformer Part Number 186F36 Online
Purchase the Hammond Series186F36 power transformer online for reliable power regulation in industrial environments. Featuring dual primary 115/230V, 36VCT secondary, UL recognition, CSA certification, and split bobbin construction, this transformer delivers consistent performance. Its open style chassis mount design and solder or quick connect terminals make installation straightforward. Designed to Class A temperature rise and tested at 2 KV RMS, it ensures safety and durability for demanding power management applications. Buy now for quality assurance and seamless project integration.
Order your Hammond Series186F36 power transformer today and ensure your industrial power regulation projects are equipped with dependable quality.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 186F36?
You can click on the BUY or RFQ button to purchase 186F36 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 186F36?
You can download the 186F36 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 186F36?
Hammond Manufacturing
