Hammond Manufacturing 186F48 industrial power transformer
This component is used for power management and industrial applications, providing reliable performance in demanding environments.
Hammond Manufacturing 186F48 industrial power transformer Specifications:
- Primary Voltage: 115/230 VAC, 50/60 Hz
- Secondary Voltage: 48V CT
- Current Rating: 2 Amps
- Power Rating: 96 VA
- Dimensions: Length 4.03 inches, Height 2.25 inches, Depth 2.56 inches (excluding terminals)
- Mounting: Chassis mount using 3/16 inch quick connect or solder lug terminals
- Insulation Material: Minimum Class B or 130°C rating
- Temperature Rise: Designed to Class A temperature rise
- Construction: Open style, channel frame with split bobbin construction
- Testing: Hi-pot tested to 2 KV RMS
- Certifications: UL recognized & CSA certified
Buy the Buy Hammond industrial power transformer Part Number 186F48 Online
Purchase the Hammond Series 186F48 industrial power transformer online today for high-performance power management in demanding environments. Featuring dual primary voltages of 115/230 VAC and a 48V CT secondary, this transformer delivers 96 VA with a 2 Amp current rating. Its open style, split bobbin design, and UL/CSA certification ensure safety and reliability. Ideal for industrial applications, it is quick and easy to install with 3/16 inch quick connect or solder lug terminals. Improve your power system efficiently by ordering now.
Order your Hammond Series186F48 industrial power transformer today and enhance your power management system with reliable, certified performance.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 186F48?
You can click on the BUY or RFQ button to purchase 186F48 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 186F48?
You can download the 186F48 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 186F48?
Hammond Manufacturing
