Hammond Manufacturing 560C Audio Transformer
This audio transformer is designed for professional sound systems, ensuring high fidelity and low distortion across a broad frequency response, making it ideal for microphones, line matching, and isolating audio signals. Its rugged epoxy-potted case with 9-pin connections provides durability and consistent performance. The product features electrostatic shielding, balanced split windings for circuit versatility, and can be reversed for impedance matching. Its compact dimensions and reliable specifications make it suitable for various audio application needs, delivering clear sound transmission with minimal insertion loss.
Hammond Manufacturing 560C Audio Transformer Specifications:
- Type: Audio transformer
- Case Material: Rugged epoxy-potted
- Connections: 9-pin
- Frequency Response: 30 Hz to 30 kHz (560Q: 30 Hz to 15 kHz)
- Insertion Loss: Maximum 1 dB
- Impedance: Primary 150/600 Ohms, Secondary 1200/4800 Ohms (depending on model)
- Dimensions: 1.64" x 1.33" x 0.85" (41.7 mm x 33.8 mm x 21.6 mm)
- Weight: 4 oz (0.1 kg)
- Features: Electrostatic shield, electrostatic shield connected to pin 'SH', balanced split windings, reversible primary & secondary
- Applications: Microphone, line matching, isolating, bridging, impedance matching
- Max Frequency Response: ±1 dB, typical ±0.5 dB, 30 Hz to 30 kHz (560Q: 30 Hz to 15 kHz)
Buy the Buy Hammond Audio Transformer Part Number 560C Online
Experience professional-grade sound quality with the Hammond audio transformer series. Designed for sound engineers and audio enthusiasts, this rugged device offers exceptional fidelity, low distortion, and versatile impedance matching. Its epoxy case ensures durability, while the electrostatic shield provides noise reduction. The compact size suits various applications such as microphones, line matching, and audio isolation. Easy to install and maintain, it guarantees reliable operation across different audio setups, elevating your sound system performance for clear, professional audio reproduction.
Order your Hammond Series560C audio transformer today and enhance your sound systems with reliable performance and optimal impedance matching.
Frequently Asked Questions
Where can I buy Hammond Manufacturing 560C?
You can click on the BUY or RFQ button to purchase 560C from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part 560C?
You can download the 560C datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of 560C?
Hammond Manufacturing
