Hammond Manufacturing 560J Audio Transformer
The 560J is a PCB-mount audio transformer with rugged black epoxy-potted construction, suitable for connecting collector to line or line to base circuit applications. It features a frequency response of approximately 30Hz to 30kHz within ±1dB (typical ±0.5dB) at 0dBm, with reduced low-frequency performance at higher signal levels. The transformer exhibits an insertion loss of no more than 1dB. It includes an electrostatic shield between the primary and secondary windings, connected to the core and accessible via the 'SH' pin. The design incorporates hum bucking construction and balanced split windings on both primary and secondary for flexibility in circuit configurations. Primaries and secondary windings can be reversed for impedance matching. Its overall dimensions are 1.64 inches by 1.33 inches by 0.85 inches high. Ideal for audio applications.
Hammond Manufacturing 560J Audio Transformer Specifications:
- Frequency response: 30Hz to 30kHz within ±1dB (typical ±0.5dB) at 0dBm
- Insertion loss: Maximum 1dB
- Construction: Rugged black epoxy-potted
- Shield: Electrostatic shield between primary and secondary, connected to core
- Windings: Balanced split on primary and secondary, reversible for impedance matching
- Primary Impedance: 150/600 Ohms (other models available)
- Secondary Impedance: 150/600 Ohms or higher (depending on model)
- Dimensions: 1.64 inches (41.7mm) x 1.33 inches (33.8mm) x 0.85 inches (21.6mm)
- Weight: 4 oz (0.1 kg)
- Application: Connecting collector to line or line to base in audio systems
