Hammond Manufacturing EN4SD20248LG Wallmount Enclosure
The Type 4 Mild Steel Wallmount Enclosure from the Eclipse Series offers robust protection for electrical and electronic equipment in harsh industrial environments. Made from formed 14 or 16 gauge steel with seamless welded seams, it features hidden hinges, a quarter turn latch with a multi-point lock, and a powder-coated finish available in ANSI 61 gray or RAL7035 light gray. The enclosure includes mounting hardware, gasket sealing, and removable doors for easy modifications, making it ideal for high-tech, industrial, and harsh environment applications. Certified for UL 508 Type 3R, 4, and 12, and IEC IP66 compliance for reliable performance.
Hammond Manufacturing EN4SD20248LG Wallmount Enclosure Specifications:
- Material: Formed 14 or 16 gauge steel
- Finish: Powder-coated in ANSI 61 gray or RAL7035 light gray
- Standards: UL 508 Type 3R, 4, 12; CSA Type 3R, 4, 12; IEC 60529 IP66
- Hinges: Stainless steel with stainless steel pins
- Latches: Zinc diecast, black epoxy finish, key lockable, quarter turn with multi-point locking system
- Seams: Welded and ground smooth
- Gasket: Seamless poured-in-place gasket
- Dimensions: 20.00 x 24.00 x 10.00 inches (Width x Depth x Height)
- Weight: 36 lbs
- Mounting: Hardware includes panel mounting nuts, sealing washers, bonding studs, grounding studs, and mounting foot kit
Buy the Hammond Series Eclipse Wallmount Enclosure: EN4SD20248LG
Secure your electrical and electronic components with the Hammond Series Eclipse Wallmount Enclosure. Engineered from heavy-duty steel and finished in durable powder coat, it offers IP66-rated protection against harsh environments. Its design features hidden hinges, a quarter turn lock, gasket sealing, and removable doors for easy access and modifications. Certified for UL 508 and IEC standards, this enclosure ensures high-performance, safety, and reliability for industrial applications. Purchase online now for fast delivery and premium quality installation solutions.
Order your Hammond Series Eclipse EN4SD20248LG today and give your industrial electrical projects the dependable, high-quality protection they deserve.
