Hammond Manufacturing R100082000 Diecast Aluminum Enclosure
The R100-082-000 is a rugged, high-quality die-cast aluminum enclosure suitable for demanding industrial environments. Designed with a shallow lid and deep body for versatile use, it features externally mounted zinc die-cast feet that rotate 90 degrees for flexible installation. With an IP66/NEMA 4X rating, it offers superior protection against dust and water ingress. The enclosure includes captive stainless steel lid screws and a neoprene gasket resistant to oil and petrol, ensuring a secure, leak-proof seal. Operating temperatures range from -40°C to 80°C, making it ideal for mining, oil, gas, and industrial applications requiring reliable enclosure solutions that meet IEC 60529 standards.
Hammond Manufacturing R100082000 Diecast Aluminum Enclosure Specifications:
- Material: Die-cast aluminum G Al SI 12/ DIN 1725, Leg 230
- Finish: Textured polyester powder coat, beige RAL 7032
- Protection rating: IP66/NEMA 4X
- Wall thickness: Thick-walled design for durability
- External mounting feet: Zinc die-cast, rotatable 90 degrees
- Sealing: Neoprene gasket resistant to oil and petrol
- Temperature range: -40°C to 80°C
- Standards: IEC 60529 compliant, IP66
- Construction: Shallow lid, deep body for versatile mounting
- Screws: Captive stainless steel lid screws
Buy the Hammond Series R100 Diecast Aluminum Enclosure: R100082000
Secure your industrial projects with Hammond's durable diecast aluminum enclosure designed for demanding environments. Featuring a shallow lid, deep body, and rotatable zinc feet, it provides versatile mounting options. Its IP66/NEMA 4X rating ensures excellent protection against dust and water ingress, while stainless steel screws and a neoprene gasket guarantee secure sealing against oil and petrol. Suitable for mining, oil and gas, and industrial applications, this enclosure meets IEC 60529 standards, offering robust performance and reliable protection over a wide temperature range.
Buy Hammond R100082000 now and experience unmatched reliability and protection for industrial environments with durable die-cast aluminum design.
Frequently Asked Questions
Where can I buy Hammond Manufacturing R100082000?
You can click on the BUY or RFQ button to purchase R100082000 from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part R100082000?
You can download the R100082000 datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of R100082000?
Hammond Manufacturing
