Hammond Manufacturing SKT011409NCC Temperature Control Thermostat
The SKT011409NC-C thermostat provides precise air temperature control and monitoring for cabinets, featuring a bi-metal sensor element that opens contact at the set point to turn off heaters when temperature rises. It is designed for HVAC applications, easily mounted on DIN rails with clip mounting, and constructed from flame-retardant plastic with IP20 protection. Suitable for controlling heaters and fans in industrial environments, this thermostat offers reliable operation with a 2-pole terminal compatible with 14 AWG wiring. Its robust design ensures safety and efficiency in temperature regulation tasks.
Hammond Manufacturing SKT011409NCC Temperature Control Thermostat Specifications:
- Sensor Element: Thermostatic bi-metal
- Adjustment Range: 30 - 140°F
- Connection: 2 pole terminal for AWG 14 (2.5 mm²)
- Housing Material: Flame retardant plastic UL94V-0
- Protection Rating: IP20
- Mounting: Clip mounting on 35 or 38 mm DIN rail
- Switching Capacity: 10 A at 120 V AC, 250 V AC
- Contact Type: Normally Closed (NC)
- Dimensions: Contact height x width approximate, suitable for DIN rail installation
- Approval: UL Recognized, cUL Recognized, CE
- Color: Gray
Buy the Hammond Series Thermostats: SKT011409NC-C
Enhance your HVAC setup with the Hammond SKT011409NC-C thermostat, offering accurate temperature regulation with bi-metal sensing and easy DIN rail installation. Its flame-retardant housing ensures safety, while the NC contact configuration helps control heaters efficiently. Suitable for industrial environments, this thermostat provides reliable switching capacity and is compatible with 14 AWG wiring. Whether for cabinet climate control or fan regulation, buy online now to ensure optimal performance and durability in your temperature management solutions.
Buy Hammond SKT011409NC-C thermostat now and experience unmatched reliability and performance in temperature control for HVAC systems.
Frequently Asked Questions
Where can I buy Hammond Manufacturing SKT011409NCC?
You can click on the BUY or RFQ button to purchase SKT011409NCC from an authorized Hammond Manufacturing distributor.
How do I troubleshoot issues or seek technical support for part SKT011409NCC?
You can download the SKT011409NCC datasheet or visit the Hammond Manufacturing website for support.
Who is the manufacturer of SKT011409NCC?
Hammond Manufacturing
