HellermannTyton 166-90136 Datasheet & Stock
The 166-90136 from Hellermanntyton is a straight, 1" NPT thread, 1" diameter, black colour HelaGuard non-metallic IP65 fitting. The compression fitting features a twist-on design for easy installation and future access. It is constructed with a polyamide 6.6 (PA66) material. Fits HelaGuard non-metallic conduits and tubing.
IP65 rating for protection against wind, dirt and low pressure jets of water from all directions
All-around "teeth" attach firmly to conduit and deliver a high extraction force
External NPT thread provides a secure connection
Twist-on installation makes future access fast and easy
Length is 48mm, bore diameter is 24.5mm
UL 94 V2 flammability rating
UL recognized
Operating temperature range from -40ðC to +120ðC
Durable nylon material has high resistance to salts, oils, weak acids and solvents
Applications
Industrial
Contents
10 per pack.
|
View 166-90136 Datasheet [pdf] |
| Source | Part No | Stock | Inv Date | Qty/Price USD | Buy/RFQ | ||
|---|---|---|---|---|---|---|---|
| Newark | 166-90136 | 1 | 05-19-2024 | Unit price: $25 | Authorized Distributors | ||
| Digi-Key Electronics | 166-90136 | 0 | 05-19-2024 | Unit price: $134.23 | Authorized Distributors |
Specifications for HellermannTyton 166-90136
