Honeywell GLLA01A2Y Miniature Industrial Limit Switch
The GLL Series miniature industrial limit switch by Honeywell is engineered for reliable performance in indoor and outdoor machinery applications. It features a double-insulated thermoplastic housing, IP66 environmental sealing, and a wide variety of actuation options including rotary, pin, and roller levers. Certified with CE, CCC, cULus, and CSA, it offers positive opening contacts, galvanically isolated poles, and flexible conduit fittings. Its design conforms to EN50047 standards, ensuring suitability for diverse industrial environments and global standards for safety and durability.
Honeywell GLLA01A2Y Miniature Industrial Limit Switch Specifications:
- Housing Material: Thermoplastic reinforced with glass fiber
- Environmental Sealing: IP66; NEMA 1, 12, 13
- Certifications: CE, CCC, cULus, CSA
- Standards: EN60947-5-1 (CE), GB 14048.5 (CCC), UL508, CSA B44.1-04/ASME-A17.5
- Conduit: 0.5-14 NPT, 20 mm
- Actuators: Side rotary, top pin, top roller, vertical roller, adjustable lever
- Contact Material: Silver alloy
- Utilization Category: AC-15, A600; DC-13, Q300
- Rated Voltage: 600 Vac, 250 Vdc
- Rated Current: 12A (AC), 0.27A (DC)
- Insulation Voltage: 600V
- Impulse Withstand Voltage: 5249 V(imp)
- Mechanical Life: Up to 5 million operations
- Operating Temperature: -10°C to 80°C
- Vibration (without actuator): 10 g per IEC 60068-2-6
- Shock (without actuator): 50 g per IEC 60068-2-27
Buy the Honeywell GLL Series – Reliable Limit Switch for Industrial Applications
Order the Honeywell GLL Series miniature industrial limit switch online today and experience precision control, durability, and versatile actuation. Designed for indoor and outdoor machinery, it offers global certifications, environmental sealing, and positive opening contacts to ensure safety and reliability in diverse industrial environments. Its robust thermoplastic housing and multiple actuator choices make it ideal for applications like lifts, gates, doors, and packaging equipment. Get yours now for superior performance and peace of mind in demanding industrial settings.
Buy Honeywell GLL Series limit switch now and ensure dependable performance with global certifications and versatile actuator options.
