Honeywell HAFUHT0015L4AXT Digital Airflow Sensor
Honeywell Zephyr™ HAF Series digital airflow sensors deliver high-precision measurements over a broad range of flow rates, including 10, 15, 20, 50, 100, 200, and 300 SLPM. Utilizing advanced ASIC and MEMS technology, these sensors provide fast 1 ms response times, temperature compensation, and digital I2C output, making them ideal for medical and industrial applications. Rugged, customizable, and RoHS-compliant, their design ensures high reliability, low power consumption, and easy integration into complex systems requiring accurate airflow monitoring.
Honeywell HAFUHT0015L4AXT Digital Airflow Sensor Specifications:
- Flow ranges: 10, 15, 20, 50, 100, 200, 300 SLPM
- Supply voltage: 3Vdc to 10Vdc
- Supply current: 20 mA max.
- Response time: 1 ms
- Accuracy: 0.5% FS to 14.3% FS, 3.5% reading from 14.3% FS to 100% FS
- Total Error Band: 0.5% FS to 12.5% FS, 4.0% reading from 12.5% FS to 100% FS, 7.0% reading at 300 SLPM
- Temperature range: 0°C to 50°C (calibrated), -20°C to 70°C (operating)
- Materials: Glass-reinforced thermoplastic, gold, silicon, silicon nitride, PCB epoxy
- Port options: Manifold mount, 22 mm OD tapered male, G 3/8 threaded
- Environmental: Humidity 0-95% RH, non-condensing; Shock 30g; Vibration 1.33g at 10-500Hz
- Digital interface: I2C, unique serial number via command, 16-bit flow reading
- Mounting: 10-32 screws, torque 1.13 N·m, with provided G3/8 or tapered fittings
- Compliance: RoHS, WEEE
Buy the Honeywell Series HAF Airflow Sensor: 15 SLPM
Discover the Honeywell Zephyr Digital Airflow Sensor from the HAF Series, designed for high accuracy and rapid response in demanding medical and industrial environments. Featuring a broad flow range from 10 to 300 SLPM, temperature compensation, and digital I2C output, it simplifies integration into complex control systems. Rugged and reliable, this sensor ensures precise airflow measurement with minimal calibration. Ideal for applications like anesthesia delivery, ventilators, fume hoods, gas monitoring, and process control, purchase online today for dependable performance and easy system integration.
Get Honeywell HAF15L4AXT today—built for precision and long-lasting durability in airflow measurement applications.
