Honeywell PX2AN1XX500PSACX Heavy Duty Pressure Transducer
Honeywell’s PX2 Series Heavy Duty Pressure Transducers are configurable pressure sensors designed for industrial applications. They employ piezoresistive sensing technology with ASIC signal conditioning in a stainless steel housing, ensuring durability and accuracy. These transducers are fully calibrated and compensated for offset, sensitivity, temperature effects, and non-linearity. They are compatible with various pressure references and port types, making them versatile for diverse industrial needs, including HVAC/R systems and air compressor monitoring. The PX2 Series offers enhanced durability and media compatibility, operating reliably in challenging conditions.
Honeywell PX2AN1XX500PSACX Heavy Duty Pressure Transducer Specifications:
- Pressure Range: 1 bar to 70 bar | 100 kPa to 7 MPa | 15 psi to 1000 psi
- Pressure Reference: Absolute, sealed gage or vented gage
- Pressure Port Types: 7/16-20 UNF 1/4 in 45° Flare Female Schrader (SAE J512), 7/16-20 UNF 45° Flare Male (SAE J513), 7/16-20 UNF 37° Flare Male (SAE J514), G1/4 (ISO 1179-3), G1/8 (ISO 1179-3), M12 x 1.5 (ISO 6149-3), 1/4-18 NPT, 1/8-27 NPT, 9/16-18 UNF (SAE J1926-3), or 7/16-20 UNF (SAE J1926-3)
- Electrical Connector Types: Metri-Pack 150 (UL 94 HB or V-0 options), Micro M12, DIN, Deutsch, or cable harness (1 m, 2 m, 3 m, or 5 m)
- Total Error Band: ±2.0 %
- Operating Temperature Range: -40°C to 125°C [-40°F to 257°F]
- Response Time: <2 ms
- Life: Minimum of 10 million cycles to operating pressure
- Mechanical Shock Rating: 100 G per MIL-STD-202F, Method 213B, Cond. F
- Vibration Rating: 20 G sweep, 10 Hz to 2000 Hz
- Ingress Protection: Up to IP69K
- Radiated Immunity Protection: Up to 100 V/m (ISO 11452-2)
- Flame Retardant Options: UL 94 HB standard on all electrical terminations; UL 94 V-0 available upon request
- Media Compatibility: Common HFC refrigerants (R410A, R134A), low GWP refrigerants (R448A, R32, R1234ZE), engine oil, hydraulic fluids, DOT 3 brake fluid, dry air
Buy the PX2AN1XX500PSACX HONEYWELL Heavy Duty Pressure Transducer | myMectronic
Purchase the Honeywell PX2AN1XX500PSACX Heavy Duty Pressure Transducer securely and efficiently through our online platform.
