Honeywell PX2AN2XX150PSAAX Heavy Duty Pressure Transducer
Honeywell’s PX2 Series Heavy Duty Pressure Transducer is a portfolio of highly configurable pressure sensors designed for demanding applications. These transducers use piezoresistive sensing technology with ASIC signal conditioning and are fully calibrated and compensated for offset, sensitivity, temperature effects, and non-linearity. With thousands of possible configurations, the PX2 Series caters to specific customer requirements, offering compatibility with harsh media, a wide operating temperature range, and robust ingress protection. Applications include industrial monitoring, HVAC/R systems, and air compressor performance analysis.
Honeywell PX2AN2XX150PSAAX Heavy Duty Pressure Transducer Specifications:
- Pressure Range: 1 bar to 46 bar, 100 kPa to 4.6 MPa, 15 psi to 667 psi
- Total Error Band: ±2%
- Operating Temperature Range: -40 ºC to 125 ºC [-40 °F to 257 °F]
- Connector Types: Delphi Metri-Pack 150, Micro M12, DIN, Deutsch, cable harness (1 m, 2 m, 3 m, or 5 m)
- Port Types: 1/4-18 NPT, 1/8-27 NPT, 9/16-18 UNF SAE J1926-3, 7/16-20 UNF SAE J1926-3, 1/4 in 45° Flare Female Schrader (7/16-20 SAE J512), M12 x 1.5 ISO 6149-3, G1/4 ISO 1179-3, G1/8 ISO 1179-3
- Pressure Reference: Absolute or sealed gage
- Output Transfer Function: Ratiometric, regulated or current
- Mechanical Shock Rating: 100 G per MIL-STD-202F, Method 213B, Cond. F
- Vibration Rating: 20 G sweep, 10 Hz to 2000 Hz
- Ingress Protection: Up to IP69K
- Radiated Immunity: 100 V/m
Buy the PX2AN2XX150PSAAX HONEYWELL Heavy Duty Pressure Transducer | myMectronic
Purchase the Honeywell PX2AN2XX150PSAAX Pressure Transducer securely and reliably through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy Honeywell PX2AN2XX150PSAAX?
You can click on the BUY or RFQ button to purchase PX2AN2XX150PSAAX from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part PX2AN2XX150PSAAX?
You can download the PX2AN2XX150PSAAX datasheet or visit the Honeywell website for support.
Who is the manufacturer of PX2AN2XX150PSAAX?
Honeywell
