Honeywell PX2EN1XX150PSCHX Heavy Duty Pressure Transducer
Honeywell’s PX2 Series Heavy Duty Pressure Transducer is a versatile solution for pressure measurement in industrial applications. Featuring piezoresistive sensing technology and ASIC signal conditioning, the PX2 Series delivers high accuracy and reliability. It's fully calibrated and compensated for offset, sensitivity, temperature effects, and non-linearity. With thousands of possible configurations, the PX2 Series caters to diverse customer needs, offering compatibility with harsh media, a wide operating temperature range, and robust ingress protection. Applications include compressor monitoring, HVAC/R systems, and general industrial processes.
Honeywell PX2EN1XX150PSCHX Heavy Duty Pressure Transducer Specifications:
- Pressure Range: 1 bar to 46 bar, 100 kPa to 4.6 MPa, 15 psi to 667 psi
- Total Error Band: ±2%
- Operating Temperature Range: -40 ºC to 125 ºC [-40 °F to 257 °F]
- Connector Types: Delphi Metri-Pack 150, Micro M12, DIN, Deutsch, cable harness (1 m, 2 m, 3 m, or 5 m)
- Port Types: 1/4-18 NPT, 1/8-27 NPT, 9/16-18 UNF SAE J1926-3, 7/16-20 UNF SAE J1926-3, 1/4 in 45° Flare Female Schrader (7/16-20 SAE J512), M12 x 1.5 ISO 6149-3, G1/4 ISO 1179-3, G1/8 ISO 1179-3
- Pressure Reference: Absolute or sealed gage
- Output Transfer Function: Ratiometric, regulated or current
- Mechanical Shock Rating: 100 G per MIL-STD-202F, Method 213B, Cond. F
- Vibration Rating: 20 G sweep, 10 Hz to 2000 Hz
- Ingress Protection: Up to IP69K
- Radiated Immunity: 100 V/m
Buy the PX2EN1XX150PSCHX HONEYWELL Heavy Duty Pressure Transducer | myMectronic
Purchase the Honeywell PX2EN1XX150PSCHX Pressure Transducer securely and efficiently through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy Honeywell PX2EN1XX150PSCHX?
You can click on the BUY or RFQ button to purchase PX2EN1XX150PSCHX from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part PX2EN1XX150PSCHX?
You can download the PX2EN1XX150PSCHX datasheet or visit the Honeywell website for support.
Who is the manufacturer of PX2EN1XX150PSCHX?
Honeywell
