Honeywell PX2EN1XX500PSCHX Heavy Duty Pressure Transducer
Honeywell’s PX2 Series Heavy Duty Pressure Transducer is a configurable pressure sensor designed for robust performance in industrial settings. Utilizing piezoresistive sensing technology and an ASIC signal conditioning, it provides accurate and reliable pressure readings across a wide range of applications, including HVAC/R systems, air compressors, and industrial automation. The PX2 Series is compatible with harsh media, features a wide operating temperature range, and offers ingress protection up to IP69K, ensuring durability and long-term performance. With thousands of possible configurations and a short lead time, the PX2 Series meets diverse customer requirements and supports demanding product development cycles.
Honeywell PX2EN1XX500PSCHX Heavy Duty Pressure Transducer Specifications:
- Pressure Range: 1 bar to 46 bar, 100 kPa to 4.6 MPa, 15 psi to 667 psi
- Total Error Band: ±2%
- Operating Temperature Range: -40 ºC to 125 ºC [-40 °F to 257 °F]
- Connector Types: Delphi Metri-Pack 150, Micro M12, DIN, Deutsch, cable harness (1 m, 2 m, 3 m, or 5 m)
- Port Types: 1/4-18 NPT, 1/8-27 NPT, 9/16-18 UNF SAE J1926-3, 7/16-20 UNF SAE J1926-3, 1/4 in 45° Flare Female Schrader (7/16-20 SAE J512), M12 x 1.5 ISO 6149-3, G1/4 ISO 1179-3, G1/8 ISO 1179-3
- Pressure Reference: Absolute or sealed gage
- Output Transfer Function: Ratiometric, regulated or current
- Mechanical Shock Rating: 100 G per MIL-STD-202F, Method 213B, Cond. F
- Vibration Rating: 20 G sweep, 10 Hz to 2000 Hz
- Ingress Protection: Up to IP69K
- Radiated Immunity: Up to 100 V/m
- Response Time: <2 ms
- Cycle Life: Minimum 10 million cycles to operating pressure
Buy the PX2EN1XX500PSCHX HONEYWELL Heavy Duty Pressure Transducer | myMectronic
Purchase the Honeywell PX2EN1XX500PSCHX Heavy Duty Pressure Transducer securely and efficiently through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy Honeywell PX2EN1XX500PSCHX?
You can click on the BUY or RFQ button to purchase PX2EN1XX500PSCHX from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part PX2EN1XX500PSCHX?
You can download the PX2EN1XX500PSCHX datasheet or visit the Honeywell website for support.
Who is the manufacturer of PX2EN1XX500PSCHX?
Honeywell
