Honeywell QFB1WHI Lighting Distribution System
This versatile connection and distribution system enhances lighting installations with a modular plug and socket interface, enabling quick, secure connections without circuit shutdown. It supports both heat resisting flexible cable and low smoke zero halogen insulated sheath, ensuring safety and durability. Features include a 'click-in' connection, inaccessible live contacts for safety, and an earth contact that connects first. Suitable for various wiring configurations, it supports portable, fixed lighting setups, and industrial environments with IP2XD rating and support for up to 6kg load, operating efficiently at -5°C to +40°C ambient temperatures.
Honeywell QFB1WHI Lighting Distribution System Specifications:
- Voltage Rating: 250V a.c. 50Hz
- Current Rating: 6 Amp
- Terminal Capacity: Phase, neutral, earth & loop in terminals accept 1 x 0.75 or 1 x 1.00mm conductors; other models support 5 x 0.75, 5 x 1.00, 4 x 1.50, 3 x 2.50 or 2x 400mm² conductors
- Physical: Supports static suspension load up to 5kg, IP2XD rated, Dimensions vary by model with diameters 25mm, 33mm, and 75mm, and lengths from 44mm to 86mm
- Materials: Insulated flexible cable with heat resisting flex or low smoke zero halogen sheath
- Ambient Temperature: -5°C to +40°C, not to exceed 25°C in any 24-hour period
- Installation: Supports conduit entries 20mm and 25mm, wall or ceiling mounting, with provisions for screw fixings and Caddy Clips; maximum installation altitude 2000 meters
Buy the Buy Industrial Connection and Distribution System Part Number QFB1WHI Online
Purchase the QFB1WHI lighting distribution system online today to ensure quick, safe, and secure connections for your lighting setup. This modular system features a plug and socket interface that allows for effortless, click-in installation, eliminating the need to shut down circuits. Its safe design includes inaccessible live contacts and a protective earth connection. Suitable for industrial, commercial, and technical lighting projects, the system supports various wiring configurations, boasts an IP2XD rating for safety, and can handle loads up to 6kg at temperatures ranging from -5°C to +40°C. Order now for reliable performance and easy installation!
Get QFB1WHI today—built for flexibility, safety, and reliable lighting connections in industrial and commercial environments.
Frequently Asked Questions
Where can I buy Honeywell QFB1WHI?
You can click on the BUY or RFQ button to purchase QFB1WHI from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part QFB1WHI?
You can download the QFB1WHI datasheet or visit the Honeywell website for support.
Who is the manufacturer of QFB1WHI?
Honeywell
