Honeywell V71C17E9201 Miniature Micro Switch
Honeywell's MICRO SWITCH™ V7 Series offers miniature pressure and limit switches designed for rugged industrial applications. These reliable, high-quality switches feature a thermoplastic housing, industry-leading temperature ranges from -40°C to 175°C, and mechanical life of up to 10 million cycles. They are suitable for controlling logic-level loads from 0.1 A to 25 A, with various actuation options including pin plungers and integral levers. Certified by CSA, ENEC, and UL, V7 switches excel in harsh conditions such as oven or pressure sensing, vending machine motors, and microwave door interlocks, ensuring performance and durability.
Honeywell V71C17E9201 Miniature Micro Switch Specifications:
- Circuitry: SPDT, SPNC, SPNO
- Operating Force: 0.25 N to 3.9 N [15 g to 397 g]
- Electrical Ratings: 0.1 A to 25 A at 125 Vac, 250 Vac, 277 Vac
- Housing Material: High strength thermoplastic
- Temperature Range: -40 °C to 175 °C [-40 °F to 347 °F]
- Mechanical Life: Up to 10 million cycles
- Contact Material: Silver, gold plated, gold alloy
- Actuators: Pin plunger, integral lever options, auxiliary lever options
- Agency Certifications: CSA, ENEC, UL
- Quick connect terminals: 4.75 mm x 0.51 mm and 6.35 mm x 0.81 mm
- Dimensions: Vary per model, typical mounting hole 3.1 mm
- Certifications: UL, CSA, ENEC
Buy the Buy Honeywell V7 Series Part Number V71C17E9201 Online
Order Honeywell V7 Series micro switches online for industrial, HVAC, and safety applications. Designed for durability with a high-temperature rating, long cycle life, and diverse actuation options. Certified globally, these switches offer flexibility with various electrical ratings up to 25 A. Perfect for controlling motors, pressure sensing, or microwave door interlocks, ensuring reliable operation in demanding environments. Purchase now to ensure high-quality, long-lasting performance for your equipment needs.
Get Honeywell V7 Series V71C17E9201 today—built for precision, long-lasting durability, and reliable performance in harsh industrial conditions.
