Honeywell WAN02RSP Wireless Limit Switch
The Honeywell WGLA Series Limitless Wireless Global Limit Switches are designed for remote position sensing and presence detection in harsh environments. Featuring IP67 sealing, 802.15.4 wireless communication at 2.4 GHz, and configurable actuatorHead options including side rotary, plunger, roller, and lever heads, these switches provide reliable, flexible, and maintenance-free operation up to 305 meters. Suitable for industrial applications such as cranes, lifts, presses, and machinery monitoring, they reduce wiring costs and facilitate remote control in challenging settings. Their rugged zinc die-cast enclosure ensures durability across various industries.
Honeywell WAN02RSP Wireless Limit Switch Specifications:
- Housing material: Powder coated zinc die-cast
- Sealing: IP67, NEMA 1, 4, 12, 13
- Wireless communication: WPAN 802.15.4, 2.4 GHz
- Range: Up to 305 meters (1000 feet)
- Power supply: 3.6 Vdc Lithium Thionyl Chloride, 2/3 AA, >1 year life
- Operating temperature: -40°C to 85°C (-40°F to 185°F)
- Signal range varies based on antennas, site topography
- Actuator options: Side rotary, plunger, roller, lever heads
- Housing dimensions: Typical - 102.9 mm x 22 mm x 16 mm
- Certifications: FCC, Industry Canada, CE, KCC, IDA, others
- Impact resistance: IEC 60068-2-27, 10 g, 6 ms
- Vibration: IEC 60068-2-6, 10-500Hz, 0.35 mm peak-to-peak
- Maximum switching frequency: 120 ops/min
Buy the Buy Honeywell Wireless Limit Switch Part Number WAN02RSP Online
Discover the Honeywell WAN02 RSP wireless limit switch, engineered for industrial remote sensing where wiring is impractical. Featuring IP67 sealing and 802.15.4 wireless technology at 2.4 GHz, this switch provides dependable, maintenance-free operation up to 305 meters. Its rugged enclosure and configurable actuator heads, including side rotary and roller options, make it ideal for applications like cranes, lifts, and machinery monitoring. Reduce wiring costs and enhance safety with this durable, versatile solution for demanding industrial environments. Buy online today for advanced remote control capabilities.
Get Honeywell WAN02RSP today—built for reliable remote sensing and harsh environment durability.
Frequently Asked Questions
Where can I buy Honeywell WAN02RSP?
You can click on the BUY or RFQ button to purchase WAN02RSP from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part WAN02RSP?
You can download the WAN02RSP datasheet or visit the Honeywell website for support.
Who is the manufacturer of WAN02RSP?
Honeywell
