Honeywell ZM50E60B01 Subminiature Basic Switch
The Honeywell MICRO SWITCH ZM50E60B01 is a subminiature snap action switch within the ZM/ZM1 series, known for its compact size and versatility. It's suitable for controlling electrical loads ranging from logic-level circuits to power-duty switching, up to 16.1 A and 250 Vac. The switch's small package size makes it ideal for applications where space is limited. It is agency certified to UL, cUL, CE, and CQC for worldwide use. Available with various lever options and electrical terminations, the ZM50E60B01 provides a robust solution for control and monitoring circuits in applications like copy machines, cash registers, HVAC systems, and hospital beds.
Honeywell ZM50E60B01 Subminiature Basic Switch Specifications:
- Operating force: 60 g
- Termination: Solder (standard and extended), PCB (standard, left, or right)
- Sealing: IP40
- Actuators: Pin plunger, straight lever, simulated roller lever, roller lever, L-shaped lever
- Agency certification: UL, cUL, CE, CQC
- Operating temperature: -40 °C to 125 °C
- Mechanical endurance: 5,000,000 min. @ 400 cycles/minute
- Switch resistance: 100 m Ω max.
- Insulation resistance: 100 M Ω min.
- Dielectric strength: 1500 V RMS
- Plunger material: PA (nylon)
- Case/cover material: PA (nylon)
- Contact material: Gold-plated silver alloy
Buy the ZM50E60B01 HONEYWELL Subminiature Basic Switch | myMectronic
Purchase the Honeywell ZM50E60B01 subminiature switch securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy Honeywell ZM50E60B01?
You can click on the BUY or RFQ button to purchase ZM50E60B01 from an authorized Honeywell distributor.
How do I troubleshoot issues or seek technical support for part ZM50E60B01?
You can download the ZM50E60B01 datasheet or visit the Honeywell website for support.
Who is the manufacturer of ZM50E60B01?
Honeywell
