IDEC Corporation CW9ZD1X1 Flush Silhouette Switch
The flush silhouette switches combine stylish, slim design with IP65/67 protection for safe, hygienic operation in various environments. Featuring USB 2.0 and RJ45 ports, these switches are easy to install with a projecting only 2.5mm from the panel surface, ensuring a secure and clean look. Suitable for panels requiring water and dust resistance, they support high connection cycles, with the USB port compliant with USB 2.0 standards and the RJ45 for reliable Ethernet connectivity. The switch's robust construction and safe operation make it ideal for industrial and automation applications.
IDEC Corporation CW9ZD1X1 Flush Silhouette Switch Specifications:
- USB Port: USB 2.0 compliant, 8-pin contacts
- RJ45 Port: Cat.6 Class EA, compliant with ISO/IEC 11801
- Operating Temperature: -25 to +70°C
- Storage Temperature: -25 to +70°C
- Relative Humidity: 0 to 90% RH, no condensation
- Connecting Cycles: USB - 1,500, RJ45 - 750
- Connecting Force: Max. 35N for USB, 10N min for RJ45
- Recommended Tightening Torque: 1.2 to 1.5 N-m
- Bezel Material: PBT, IP65/67 protection
- Panel Thickness: 1.5 to 5 mm with gasket mount
- Dimensions: Bezel projecting 2.5mm from panel; back depth 39.9mm
- Water/Dust Resistance: IP65/67 with attached accessories
- Cable Length: USB 1M, RJ45 fits standard Ethernet cables
Buy the IDEC Series Flush Silhouette Switches: CW9ZD1X1
Purchase IDEC flush silhouette switches CW9ZD1X1 online today and enhance your control panels with stylish, slim design. These IP65/67 water- and dust-proof switches feature USB 2.0 and RJ45 ports, projecting only 2.5mm from the panel for a clean, secure appearance. Designed for easy installation, they support high connection cycles and provide reliable Ethernet and USB connectivity for industrial automation. Invest now to upgrade your panels with durable, hygienic switches built for demanding environments.
Buy IDEC flush silhouette switches CW9ZD1X1 now and experience unmatched reliability, sleek styling, IP65/67 protection, and easy installation for industrial panels.
Frequently Asked Questions
Where can I buy IDEC Corporation CW9ZD1X1?
You can click on the BUY or RFQ button to purchase CW9ZD1X1 from an authorized IDEC Corporation distributor.
How do I troubleshoot issues or seek technical support for part CW9ZD1X1?
You can download the CW9ZD1X1 datasheet or visit the IDEC Corporation website for support.
Who is the manufacturer of CW9ZD1X1?
IDEC Corporation
