IDEC Corporation HS9ZA66 Safety Switch
The HS9Z-A66 is an angle-adjustable solenoid locking safety switch designed for reliable access control in industrial safety systems. Its metal actuator can be oriented for horizontal or vertical installation, with a maximum retention force of 500N. Conforming to standards including UL 508, CSA, IEC 60947-5-1, and EN 60947-5-1, it operates within a temperature range of -40 to +80°C, ensuring durability in harsh environments. The switch features LED indicators, manual unlock capability, and easy mounting, making it ideal for safety door interlocks and machinery protection.
IDEC Corporation HS9ZA66 Safety Switch Specifications:
- Conforms to UL 508, CSA C22.2 No. 14, IEC 60947-5-1, EN 60947-5-1, GS-ET-19
- Operating Temperature: -40°C to +80°C
- Storage Temperature: -40°C to +80°C
- Rated Insulation Voltage (U): 300V
- Main & lock monitor circuit voltage withstand: 1.5KV
- Impact Resistance: 1000 m/s² (100G)
- Vibration Resistance: 10-55Hz, amplitude 0.35mm
- Contact Resistance: 500mΩ max
- Insulation Resistance: 100MΩ minimum at 500V DC
- Retension Force Max: 500N
- LED Indicator: Green
- Electric Shock Protection Class: Class II
- Degree of Protection: IP67
- Mechanical Life: 1,000,000 operations
- Electrical Life: 1,000,000 operations
- Rated Voltage: 24V DC, Current: 110mA
- Dimensions: 75 x 15 x 75 mm
- Mounting Hole Layout: Compatible with M4 screws, tightening torque 1.0-1.5 N·m
Buy the IDE Series HS9Z Angle-Adjustable Solenoid Locking Safety Switch: HS9ZA66
Order the IDEC HS9ZA66 safety switch online today and experience its robust design with angle adjustability, high retention force, LED indicators, and manual unlock features. This industrial-grade safety component is perfect for machinery protection, interlocking doors, and safety systems. Its compact size and IP67 rating deliver durability in harsh environments. With high electrical and mechanical lifespan, this switch ensures long-term reliable operation, making it an essential part for safety-sensitive machinery and industrial automation applications.
Buy IDEC HS9ZA66 angle-adjustable solenoid safety switch now and ensure reliable safety control with easy mounting and manual unlocking.
Frequently Asked Questions
Where can I buy IDEC Corporation HS9ZA66?
You can click on the BUY or RFQ button to purchase HS9ZA66 from an authorized IDEC Corporation distributor.
How do I troubleshoot issues or seek technical support for part HS9ZA66?
You can download the HS9ZA66 datasheet or visit the IDEC Corporation website for support.
Who is the manufacturer of HS9ZA66?
IDEC Corporation
