IDEC Corporation LBW6MLA1RT64WS Illuminated Pushbutton
The LBW6MLA1RT64WS is an illuminated pushbutton featuring a metallic bezel with a guard, composed of high-quality materials for durability. It includes a white lens with LED illumination suited for precise signaling applications, and supports both gold and silver contacts for versatile switching. Designed with a spring-return guard that opens 180°, it ensures safe operation in industrial environments. Its compact size and panel mounting capability make it ideal for space-sensitive control panels, offering reliable performance with a rated operating voltage of 24V AC/DC and protection degree IP65, compliant with UL, CSA, and IEC standards.
IDEC Corporation LBW6MLA1RT64WS Illuminated Pushbutton Specifications:
- Shape: Round / Metallic Bezel with Guard
- Operation: Maintained and Momentary (24V AC/DC)
- Contact Material: Gold and Silver contacts
- Illumination: LED with white lens
- Protection Degree: IP65 (IEC 60529)
- Panel Thickness: 0.5 to 3.2mm
- Mounting: Panel mount with locking ring
- Rated Operating Voltage: 24V AC/DC
- Current Draw: Not specified (LED included)
- Dielectric Strength: 2,500V AC, 1 minute
- Operating Temperature: -25°C to +60°C
- Vibration Resistance: 5 to 55 Hz, amplitude 0.5mm
- Shock Resistance: Up to 1,000 m/s²
- Certification: UL, CSA, EN60947-5-1
- Material: Polyamide and stainless steel
- Dimensions: Diameter approx. 16mm; panel cutout compatible with LBW series
- Application: Industrial control panels, automation systems, remote signaling
Buy the Buy IDEC LBW6MLA1RT64WS Part Number 16mm Metallic Bezel Guard Illuminated Pushbutton Online
Order the IDEC LBW6MLA1RT64WS illuminated pushbutton online today. Featuring a durable metallic bezel, IP65 protection, and LED illumination, it is ideal for space-efficient control panels. Suitable for industrial automation, it supports 24V AC/DC operation and offers reliable switching with gold and silver contacts. Its compact design ensures easy installation and maintenance, providing excellent visibility and safety with a spring-return guard that opens 180°. Perfect for demanding environments requiring high performance and safety standards.
Get IDEC LBW6MLA1RT64WS today—built for precision and long-lasting durability in harsh industrial environments.
Frequently Asked Questions
Where can I buy IDEC Corporation LBW6MLA1RT64WS?
You can click on the BUY or RFQ button to purchase LBW6MLA1RT64WS from an authorized IDEC Corporation distributor.
How do I troubleshoot issues or seek technical support for part LBW6MLA1RT64WS?
You can download the LBW6MLA1RT64WS datasheet or visit the IDEC Corporation website for support.
Who is the manufacturer of LBW6MLA1RT64WS?
IDEC Corporation
