IDEC Corporation SV9ZPW10H1120 Industrial Interface Relay
IDEC 6mm interface relays offer a compact and reliable solution for general-purpose switching in automation and industrial applications. Available in electromechanical and solid-state models, they are suitable for PLC interfaces, panel building, and machinery control. With options for hazardous locations, these relays feature gold-plated contacts, pre-assembled DIN mount sockets, and surge suppression. They operate across a wide temperature range, include universal screw and spring clamp terminals, and are RoHS compliant, ensuring durability and versatility in demanding environments.
IDEC Corporation SV9ZPW10H1120 Industrial Interface Relay Specifications:
- Model: RV8H-L, RV8S-L, RVBH-L-D6, RVBS-L-D6, and others
- Contact Ratings: 6A contact rating, 250V AC, 30V DC
- Operating Temperature: -40°C to +70°C (electromechanical), -20°C to +60°C (SSR)
- Contact Material: Silver alloy with gold plating (for electromechanical)
- Dielectric Contact Strength: 4000V AC (electromechanical), 2500V AC (solid-state)
- Vibration Resistance: 49m/s² (5G), 29.4m/s² (3G) for electromechanical relays
- Shock Resistance: 980m/s² (100G)
- Mechanical Life: Over 10 million operations
- Operating Humidity: 5-85% (non-condensing)
- Weight: Ranges from 26g to 269g depending on model
- Enclosure: Solid State relays with built-in surge suppression, electromechanical with solid-metal housing
- Control Voltage Range: 8V to 240V AC/DC depending on model
- Certification: UL/c-UL Listed, RoHS compliant
- Mounting: Pre-assembled DIN rail mount, universal screw or spring clamp terminals
- Hazardous Locations: Class I Division 2, Zone 2 options available
Buy the IDEC RV8 Series – Reliable Interface Relays for Industrial Applications
Upgrade your automation system with IDEC interface relays available online now. These compact, reliable relays feature electromechanical and solid-state models, suitable for PLC integration, panel building, and machinery control. They are designed for demanding environments, with models for hazardous locations, surge suppression, and high switching capacity. Easy to install with pre-assembled DIN mount sockets and versatile terminals, IDEC relays ensure long-lasting, maintenance-free operation. Purchase today to enhance performance and reliability in your industrial applications.
Get IDEC RV8 Series relays today—built for precision, durability, and versatile industrial automation control.
Frequently Asked Questions
Where can I buy IDEC Corporation SV9ZPW10H1120?
You can click on the BUY or RFQ button to purchase SV9ZPW10H1120 from an authorized IDEC Corporation distributor.
How do I troubleshoot issues or seek technical support for part SV9ZPW10H1120?
You can download the SV9ZPW10H1120 datasheet or visit the IDEC Corporation website for support.
Who is the manufacturer of SV9ZPW10H1120?
IDEC Corporation
