IDEC ASD3320NU Heavy Duty Pushbutton
The IDEC TWND series of 30mm pushbuttons provides a robust and attractive solution for industrial applications. Built with chrome-plated zinc locking rings, die-cast zinc mounting threads, and self-cleaning contacts, these switches offer long-lasting performance and durability. Available in various button sizes, configurations, and with LED illumination options, the TWND series caters to diverse switching needs, ensuring reliable operation in demanding environments. They are suitable for applications requiring industrial-strength quality and long-term reliability.
IDEC ASD3320NU Heavy Duty Pushbutton Specifications:
- Button Sizes: Up to 2 9/16” (65mm)
- Construction: Chrome plated zinc locking ring, die cast zinc mounting thread
- Illumination: LED
- Voltage: Transformer or full voltage
- Contacts: Slow make, double break wiping
- UL Type: 4X, 13
- IP Rating: IP65
- Operating Temperature: -25 to +50°C (illuminated), -25 to +70°C (non-illuminated)
- Storage Temperature: -40 to +80°C
- Vibration Resistance: 5 to 55Hz
- Shock Resistance: 980m/sec
- Electric Shock Protection: Class 2
- Mechanical Life: 5,000,000 operations (momentary), 500,000 (other switches)
- Pollution Degree: 3
- Rated Operational Characteristics: AC-15: A600
- Rated Insulation Voltage: 600V
- Rated Impulse Withstanding Voltage: 2.5kV AC
- Rated Thermal Current: 10 Amp
- Minimum Switching Capacity: 5 mA at 3V AC/DC
- Contact Operation: Slow break NC or NO
- Operating Force: 6.2±2N (momentary), 9.0±1.5N (extended)
- Terminal Torque: 1.0 to 1.3 Nm
- Contact Resistance: 50mΩ or less
- Contact Gap: 2mm (NO-EM and NC-LB)
- LED Ratings: 6V: 8mA, 12V: 11mA, 24V: 11mA, 120V: 8.8mA, 240V: 8.6mA
- Contact Material: Silver
Buy the ASD3320NU IDEC Heavy Duty Pushbutton | myMectronic
Purchase the IDEC ASD3320NU 30mm Pushbutton securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy IDEC ASD3320NU?
You can click on the BUY or RFQ button to purchase ASD3320NU from an authorized IDEC distributor.
How do I troubleshoot issues or seek technical support for part ASD3320NU?
You can download the ASD3320NU datasheet or visit the IDEC website for support.
Who is the manufacturer of ASD3320NU?
IDEC
